How Intel Foundry uses Foveros stacking, EMIB silicon bridges, and EMIB-T to scale chiplets, bypass the reticle limit, and power massive AI workloads. #
As AI demands unprecedented "brain power," the semiconductor industry is moving past the era of relying on single, massive chips. Advanced packaging is the essential craft of interconnecting multiple specialized chips together. This allows them to function as a single, powerful unit that runs faster handling the massive workloads of the future.
Intel’s been doing advanced chip packaging for years in the U.S. and across the globe. It’s one of the most crucial parts of creating multi-chip packages for today’s technology products.
U.S. Advanced Packaging: Intel’s New Mexico Facilities
Inside Intel's Rio Rancho, New Mexico facilities, advanced packaging technologies are expanding the "reticle limit"—scaling packages to 8x the industry standard today, and over 12x by 2028.
We’ve moved past the era of one big chip to a system of chips, almost like a “silicon mosaic”, where specialized tiles are interconnected in a single, massive package.
“Back in the 1980s this site was the leader in 6-inch wafer manufacturing. Now over 40 years later, things have flipped and this site is the leader in the United States for advanced packaging,” explains Katie Prouty, manager of Intel’s Fab 9 advanced packaging facility in New Mexico.
To meet the massive demands of AI, Intel is pushing the boundaries of what’s physically possible. Intel Foundry is building up with Foveros stacking, and across with EMIB interconnects.
“Some of the customers are coming to us first for advanced packaging,” Prouty says. “When we’re successful delivering to those customers, they’ll continue to grow their trust and faith in Intel as a foundry.”
What started in Rio Rancho, New Mexico as 25 employees in 1980, has now proudly grown to 2,700 employees and 500 suppliers bringing critical U.S. advanced packaging technology to market.
What is Intel Foundry’s Foveros Advanced Packaging Process?
One of the advanced packaging processes happening at Intel New Mexico’s Fab 9 focuses on connecting smaller specialized chip tiles, or chiplets, into a single, high-performance system. A technology called Foveros allows Intel Foundry to connect these chiplets on a silicon interposer. It is easiest to think of that interposer like a pizza crust.
“Inside the fab, the chip attach tool is the first step in Intel’s Foveros advanced packaging process,” says Chris Seibert, Principal Engineer at New Mexico’s Fab 9. “If we use a food analogy, this is the tool that brings in a ‘pizza crust’, or silicon wafer, and whatever ‘pizza toppings’ or specialized chiplets you want, we feed into the other side of this machine, and it attaches them to the top of that ‘crust’.”
Then it travels to a different tool that acts as a literal oven to bake that system together. Once it comes out, the overhead robot track system called FOUPs (front-opening unified pods) bring the wafer to another machine where epoxy fills in under and around those “pizza toppings” to make sure everything is pressed together.
Finally, the wafers are diced into individual packages in another tool using water-cooled blades for precision. “The great part about that process is it lets us take a bunch of different chips from different designs or different technology nodes and put them all together onto one wafer,” Seibert says.
Using Foveros technology, individual chiplets function as a single, powerful unit that runs faster while handling massive workloads. Foveros helps laptop batteries last longer by placing power-hungry circuits on more power efficient process nodes. Laptops can become thinner, and edge computing devices can fit into smaller spaces without sacrificing performance. Foveros also allows for more features to be packed into a smaller footprint, from the factory floor to your desk. **What is EMIB? Intel Foundry’s Embedded Multi-Die Interconnect Bridge Technology **
** **Part of the advanced packaging process of semiconductors includes a technology called EMIB (Embedded Multi-Die Interconnect Bridge), where specialized chips are linked together on a package with tiny silicon bridges. This approach allows different chips to work as a single unit, providing the massive power needed for AI while improving efficiency and reducing manufacturing costs.
While other foundries might use expensive silicon interposers as the connection layer between chips, Intel Foundry embeds tiny, high-speed silicon bridges only where they’re needed. It’s a data shortcut that slashes costs and turns this “silicon mosaic” of chiplets into an AI powerhouse. ** **For example, when you have large data center chips next to each other, EMIB creates a bridge right underneath so they can talk to each other.
What is EMIB-T and How Does it Deliver Power?
In 2026 the latest development is EMIB-T, which adds channels through that bridge to deliver power directly to the chips, instead of around it, which improves power efficiency and signal routing required by the latest high-bandwidth memory (HBM) technologies.
It’s more than speed; it is freedom. Only Intel Foundry can mix and match chiplets from different sources directly onto the industry’s largest substrates. That flexibility is how we build the massive, side-by-side AI engines that run today’s data centers.
