Group-GEMM in XLA: Making Mixture-of-Experts Fast and Memory-Efficient

Mixture-of-Experts (MoE) models have become a standard in most recent LLMs (DeepSeek, Grok-1, Llama-4, Gemini). But under the hood, an MoE layer turns into something that GPUs and math libraries have historically been bad at: a large collection of small, independent matrix multiplications, each with a different, data-dependent shape.

In JAX, users can describe this collection of matrix multiplications using an operation called ragged-dot, as shown in the following code snippet:

lhs = jnp.array([
    [1.0, 0.5, 0.0, 1.0],
    [0.2, 1.0, 0.5, 0.0],
    [1.0, 1.0, 1.0, 1.0],
    [0.1, 0.2, 0.3, 0.4],
    [0.5, 0.5, 0.5, 0.5]
], dtype=jnp.float32)

rhs = jnp.array([
    [[1.0, 0.0, 0.1], [0.1, 1.0, 0.0], [0.0, 0.1, 1.0], [1.0, 1.0, 0.0]], # Expert 0
    [[0.5, 0.5, 0.5], [0.2, 0.2, 0.2], [0.3, 0.3, 0.3], [0.4, 0.4, 0.4]]  # Expert 1
], dtype=jnp.float32)

group_sizes = jnp.array([3, 2], dtype=jnp.int32)

output = jax.lax.ragged_dot(lhs, rhs, group_sizes)

Hence, even though the number of groups (i.e., the number of matrix multiplications) is known at compile time (since Dimension 0 of rhs and group_sizes are equal to the number of matrix multiplications), the number of rows (i.e., the number of tokens) to be extracted from lhs for each group is determined by the contents of group_sizes and is not known until runtime. In other words, while the sizes k and n of each m x k x n matrix multiplication are known at compile time, the size m is not known until runtime, which is highly impractical for efficient computation and optimization.

The naive way to run this operation is to pad everything into a single dense batched matmul — which wastes both compute (on the padding) and memory (on the copies). The better way is a primitive called Group-GEMM: a batched matmul in which each matrix in the batch can have a different shape, computed in a single operation.

This post walks through how XLA now lowers the ragged-dot operation to real Group-GEMM through two GPU backends:

• an AMD-specific backend built on hipBLASLt (AMD ROCm), and
• a new portable code-generation backend built on Triton that runs on both CUDA and ROCm.

By the end, you’ll understand what MoE looks like to a compiler, what ragged-dot is, why Group-GEMM is the natural solution, and how each of the two backends makes it work on the GPU.

The post is organized in five parts:

• Part 1 — Why MoE Turns Into a “Ragged” Matmul Problem sets up the problem: how an MoE layer becomes a ragged matmul, why the padded baseline is wasteful, and why Group-GEMM is the right primitive.
• Part 2 — Backend #1: hipBLASLt Group-GEMM (AMD ROCm) covers the vendor-library backend, and how it bridges XLA’s compile-time planning with runtime group sizes.
• Part 3 — Backend #2: Triton Ragged-Dot (Portable CUDA + ROCm) covers the portable code-generation backend, with one emitted kernel perragged-dot variant.
• Part 4 — Performance Evaluation measures both backends against the padded baseline on MI300 and MI350, using MaxText MoE models.
• Part 5 — Conclusion and Next Steps wraps up and outlines what comes next.

Part 1 — Why MoE Turns Into a “Ragged” Matmul Problem# #

A Quick Refresher: Dense FFN vs. Mixture-of-Experts#

In a standard Transformer, every token passes through the same Feed-Forward Network (FFN). If you want the model to “know more,” you make that FFN bigger — but then every token pays for the extra parameters, and compute grows with model size.

Mixture-of-Experts breaks that link. Instead of one big FFN, an MoE layer has many smaller FFNs called experts. A small router (a gating network) looks at each token and picks the top-k experts that should process it (often k=1 or k=2). Only those experts run for that token.

The result: you can add a lot of parameters (many experts) while keeping the per-token compute roughly constant, because each token only visits a couple of experts. Figure 1 below summarizes this flow.

The Consequence for a Compiler: Variable-Size Groups#

Here’s the crucial systems detail. Because the router assigns each token to experts based on the token’s content, the number of tokens that land on each expert is different, and it is only known at runtime. One expert might receive 2,000 tokens this step; its neighbor might receive 50; the split changes with every batch.

If we gather all the tokens routed to the same expert into a contiguous block, an MoE layer becomes:

• A stack of token rows, partitioned into G contiguous groups (one per expert), where groupg hasm_g rows and them_g values vary and are runtime-dependent.
• Each expert g has its own weight matrix, so we need to computeoutput_g = tokens_g × W_g , i.e. a matmul of shape[m_g, k] × [k, n] .

Figure 2 illustrates groups with unequal sizes: each color represents an expert.

The mental model to keep for the rest of this post:

An MoE layer is a batch of matmuls whose left-hand-side rows are split into contiguous, variable-size groups.

That “variable-size groups” property is what we call ragged.

The Naive Support, and Why It Hurts: Padded-Dot#

GPUs are well suited to regular, dense shapes. So the naive solution is to force the ragged problem back into a dense one:

1. Pick a fixed capacity C (a maximum number of tokens per expert).
2. Pad every expert’s token block up to C rows.
3. Now every block has the same shape, so we can run one big batched GEMM overE × [C, k] × [k, n] .

Figure 3 illustrates this padding process: every expert’s block is padded to the same C rows, where the grey padding is compute the GPU performs for nothing.

This works, but it is wasteful in two ways:

• Wasted compute. Any expert that received fewer thanC tokens still does a fullC -row matmul; the padding rows are pure overhead.
• Wasted memory and bandwidth. The compact ragged input has to be expanded intoE padded matrices, and the outputs have to be compacted again afterwards. Those scatter/gather and pre/post-processing steps cost extra memory and memory traffic.

This “expand into padded matrices” approach is exactly the XLA baseline we’ll compare against later.

The Ragged-Dot Operation#

Rather than having users replace their MoE with a dense problem, JAX lets you describe the ragged computation directly with ragged_dot.

The basic form:

jax.lax.ragged_dot(lhs, rhs, group_sizes, ...)

with the shapes:

• lhs is 2D:[m, k] — all the tokens, stacked, in group order.
• rhs is 3D:[group, k, n] — one weight matrix per group (per expert).
• group_sizes is 1D:[group] — how many rows oflhs belong to each group.
• the output is 2D.

The group_sizes operand is the key: it is a small vector, known only at runtime, that partitions the m rows of lhs into contiguous groups. For example group_sizes = [m_g0, m_g1, m_g2] means the first m_g0 rows are group 0, the next m_g1 rows are group 1, and so on.

Note that jax.lax.ragged_dot is a JAX-level operation. When the JAX program is compiled, it is converted into the HLO ragged-dot operation (kRaggedDot), which is the actual input XLA receives and lowers.

Figure 4 illustrates the operands of a ragged-dot.

JAX also offers a more general form:

jax.lax.ragged_dot_general(lhs, rhs, group_sizes, ragged_dimension, ...)

which lets you choose which dimension is the ragged one. That choice yields the three variants listed in Table 1 and drawn in Figure 5:

Table 1: The three ragged-dot variants exposed by jax.lax.ragged_dot_general.

Variant	Ragged dimension	What it means	Group index in output?
Non-contracting (m )	the “rows” dimension	the classic MoE case	No
Contracting (k )	the reduction dimension	groups along the contracted axis	Yes
Batch (b )	a batch dimension	effectively a regular batched GEMM	—

Inside XLA these correspond to the kRaggedDot variants kRaggedNonContracting, kRaggedContracting, and kRaggedBatch. For MoE, the one that matters most is non-contracting, where the rows (tokens) are ragged.

Why Group-GEMM Is the Suitable Solution#

Group-GEMM is an API for matrix multiplication that generalizes the usual batched GEMM: instead of requiring every matrix in the batch to share the same shape, it lets each one differ — in size, transposition, activation, and scaling factors. In other words:

Group-GEMM = a set of independent GEMMs of different shapes, computed in a single operation.

That is a perfect match for ragged-dot, as ragged-dot is nothing more than a set of independent GEMMs of different shapes where the pointer to the input data can be calculated from the base pointer of the operand buffer + an offset derived at runtime from the group-size operands. Hence, Group-GEMM can take care of “unpacking” the ragged operand and computing all of the per-expert products in one kernel launch, with no padding, as shown in Figure 6.

Compared to the padded-dot baseline, this directly removes both costs described in The Naive Support, and Why It Hurts: Padded-Dot:

• No padding FLOPs — each group does exactly the work it needs.
• No expansion/copies — the compact ragged layout is consumed as-is.

The rest of this post is about the two backends XLA uses to turn ragged-dot into real Group-GEMM for AMD GPUs.

Part 2 — Backend #1: hipBLASLt Group-GEMM (AMD ROCm)# #

Overview#

AMD’s hipBLASLt library has supported Group-GEMM since version 1.2.2.

XLA already had a hipBLASLt backend for ordinary dot operations, so the natural move was to extend that existing backend to also lower ragged-dot down to hipBLASLt Group-GEMM.

Figure 7 shows the lowering path of a plain dot, and Figure 8 the ragged-dot path added alongside it.

The implementation reuses the existing matmul backend machinery and simply derives a GroupedMatmulPlan class from MatmulPlan, including the additional parameters required to run the hipBLASLt Group-GEMM.

struct GroupedGemmConfig {
  uint64_t m, n, k;
  uint64_t batch_count;
  uint64_t group_count;
  int64_t lhs_leading_dim_stride;
  int64_t rhs_leading_dim_stride;
  int64_t c_leading_dim_stride;
  int64_t output_leading_dim_stride;
  blas::Transpose trans_a, trans_b;
  bool must_swap_operands;
  xla::complex128 alpha;
  double beta;
  blas::DataType type_a, type_b, type_c, type_d;
  int64_t stride_ragged_dim;
  int64_t stride_group_dim;
  int64_t c_stride_ragged_dim;
  int64_t output_stride_ragged_dim;
  // PrecisionConfig-level algorithm
  xla::PrecisionConfig::Algorithm precision_algorithm;
  int64_t compute_precision;
  RaggedDotMode ragged_mode;
  std::optional<blas::ComputationType> compute_type;

  static absl::StatusOr<GroupedGemmConfig> FromProto(
      const xla::GroupedGemmConfigProto& proto);
  xla::GroupedGemmConfigProto ToProto() const;
};

class GroupedMatmulPlan : public gpu::BlasLt::MatmulPlan {
   public:
    friend class BlasLt;

    GroupedMatmulPlan(const BlasLt& blas_lt, const gpu::GroupedGemmConfig& cfg)
        : blas_lt_(blas_lt), cfg_(cfg) {}

    ~GroupedMatmulPlan() override = default;

    absl::Status ExecuteOnStream(
        Stream* stream, const gpu::BlasLt::MemoryArgs& args,
        blas::ProfileResult* profile_result) const override;

    absl::StatusOr<std::vector<MatmulAlgorithm>> GetAlgorithms(
        size_t max_algorithm_count, size_t max_workspace_size) const override;

    absl::Status SetAlgorithm(const MatmulAlgorithm& algorithm) override {...}

   private:
    ...

    const BlasLt& blas_lt_;
    gpu::GroupedGemmConfig cfg_;
    Epilogue epilogue_ = Epilogue::kDefault;
    std::unique_ptr<hipblaslt_ext::GroupedGemm> grouped_gemm_;
    mutable std::optional<hipblasLtMatmulAlgo_t> algorithm_;
    mutable bool algorithm_dirty_ = false;
    mutable DeviceAddressBase saved_address_workspace_{};
    // Saved default activation parameters from hipBLASLt
    int32_t activation_type_ = 0;
    int8_t bias_type_ = 0;
  };  // class GroupedMatmulPlan

(source code available GroupedGemmConfig and GroupedMatmulPlan)

The hipBLASLt Group-GEMM API#

Launching a Group-GEMM with hipBLASLt follows the fixed sequence of steps shown in Figure 9:

The important concept here is user arguments. hipBLASLt describes each individual matmul in the group with its own descriptor — a small structure that says how much data to read and from where: the matmul’s sizes, its input pointers, and its strides. There is one descriptor per matmul, and all of them must live in GPU global memory at the moment the Group-GEMM launches. (See here for more details on the user argument structure definition).

The Compile-Time vs. Runtime Problem#

Here is the central difficulty. XLA is an ahead-of-time compiler: it wants to plan and configure the operation at compile time. But the whole point of ragged-dot is that the group sizes — and therefore each matmul’s dimensions — are only known at runtime. So, we need a way to delay the specification of the matmul’s dimensions to runtime.

Fortunately, hipBLASLt provides a neat trick to bridge the gap. The extension allows the operation sizes (m, n, k, and batch) to be redefined at runtime, in device memory, by modifying the user arguments. Only one condition must be guaranteed: the total problem size defined at compile time must be equal to or greater than the sum of the sizes of all the individual GEMMs that are actually executed. (You can see the documentation for more details on this.)

In XLA, the definition of user arguments is therefore delayed until runtime. Just before launching the Group-GEMM, XLA executes small update kernels on the GPU that compute and populate the descriptors with the actual sizes of the groups contained in group_sizes.

These kernels proceed as sketched in Figure 10:

Each thread is responsible for one matmul’s descriptor. It uses a prefix sum (a block-scan) over the group sizes to figure out where its group starts in the packed buffers, computes the correct sizes, strides, scales, and data pointers, and writes them to a shared-memory staging buffer. After a synchronization, all threads cooperatively copy the completed set of descriptors into global memory, where hipBLASLt expects to find them at launch.

Autotuning#

hipBLASLt’s Group-GEMM API can enumerate all the algorithms available for a given problem, and XLA’s autotuner benchmarks them to pick the fastest, as shown in Figure 11:

However, ragged-dot needs one special accommodation. By default, the autotuner profiles candidates on buffers filled with random values. But for Group-GEMM, group_sizes is not ordinary data: its values are used to compute memory offsets and pointers. Random group sizes would produce invalid offsets and corrupt (or crash) the memory accesses.

To address this problem, the autotuner was enhanced to seed the group_sizes buffer with consistent values before profiling. More specifically, the sum of the group_sizes values must be equal to the size M of the ragged dimension.

For example, for a ragged dimension of size M = 1024 split across G = 4 groups, the autotuner seeds group_sizes = [256, 256, 256, 256] (256 × 4 = 1024 = M). When M is not divisible by G, the remainder is spread over the first groups (e.g. M = 1002 → [251, 251, 250, 250]). In both cases sum(group_sizes) == M.

Enforcing sum(group_sizes) == M guarantees two things:

1. In-bounds pointers. Each group’s data pointer is derived from a prefix sum overgroup_sizes (group_ptr = base_ptr + prefix_sum(group_sizes)[i] * stride ); keeping the sum equal toM ensures every derived pointer stays inside the operand buffer.
2. A fully-written output.ragged-dot allowssum(group_sizes) < M , but then part of the output buffer is left unwritten — during autotuning this would leave uninitialized (garbage) values that make result comparison unreliable. Seeding the sum to exactlyM ensures the entire output is written, so profiled candidates can be compared safely.

Part 3 — Backend #2: Triton Ragged-Dot (Portable CUDA + ROCm)# #

Motivation#

Even though the hipBLASLt path provides impressive performance (see Part 4 — Performance Evaluation), it is ROCm-specific and not even available on every AMD GPU target. On the other hand, Triton is a generic backend that can be lowered to most GPU targets. In addition, Triton kernels can more easily be fused together, making it a privileged backend for the XLA compiler, which aims to run on any GPU target.

Consequently, we decided to propose a Triton backend as an alternative to efficiently handle the ragged-dot operation in XLA. In a nutshell, the Triton backend consists of lowering the ragged-dot operation into a Group-GEMM Triton kernel, through XLA’s Triton tiling-and-emission pipeline.

The Compilation Pipeline#

Figure 12 shows the main steps that have been enhanced to enable the lowering of the ragged-dot op:

1. Backend selection. XLA decides which path serves thisragged-dot , following a priority order: cuDNN (CUDA) → hipBLASLt (ROCm) → Triton → a default fallback. When the Triton path is chosen, XLA wraps theragged-dot in a custom Triton fusion and seeds it with default tile sizes that the autotuner can later override. Note that the backend selection order is currently fixed by static rules, but the next step is to let the XLA autotuner choose the best backend for each specific problem’s inputs.

2. Support validation. Before committing, XLA checks theragged-dot is actually supported: it must be aragged-dot with exactly one ragged left-hand-side dimension, the tiling-propagation feature must be enabled, and the element types must be supported.

3. Scheduling. XLA decides how theragged-dot ’s logical dimensions (M, N, G, K) map onto the GPU grid — which become parallel grid axes (one program per tile, run concurrently) and which stay sequential (a loopinside a program, typically the K reduction).This step includes an M/N-swap heuristic. This heuristic already existed for the ordinary dot (andscaled_dot ) but has been extended forragged-dot . It is therefore useful to briefly recall what it does for a plain GEMM.Plain GEMM. For a regularLHS[M,K] × RHS[K,N] → out[M,N] , the M and N tiles form a 2-D grid that XLA linearizes into a 1-D stream of program IDs. Whichever axis is placedouter varies slowly, and theinner one varies fastest across consecutive programs. The heuristic exploits this to maximize L2 reuse: if the LHS (activations) issmaller in bytes than the RHS (weights), it swaps M and N so that N is traversed slowly — keeping the small LHS tile-row resident in L2 while streaming across the many N tiles. Concretely it comparesByteSizeOf(lhs) againstByteSizeOf(rhs) and, when the LHS is smaller, emits a permutation that swaps the M and N grid axes.Ragged-dot. A ragged-dot is not one big matmul butG smaller ones, so the raw operand byte-sizes are the wrong thing to compare. The ragged version keeps thesame mechanism (permute the parallel grid axes before the program-id is delinearized) but changes thedecision : it uses the compile-time estimateM_avg = M_total / G — the average number of rows per group — as a proxy for how tall each group’s LHS activation slice really is (the true per-group sizes are only known at runtime).

4. Autotuning. The pipeline generates candidate tiling configurations specialized for ragged-dot and benchmarks them (more on the ragged-specific profiling wrinkle inAutotuning and the group_sizes Seeding Problem ).

5. Emission. Finally, XLA emits the actual Triton kernel for the selected variant.

What the Emitted Triton Kernel Does, per Variant#

Now, let’s take a closer look at the Triton kernels generated to execute the generic ragged-dot operations, which encompass three variants depending on which dimension is the ragged dimension. As we argued before, the Group-GEMM algorithm is best suited to handle ragged-dot operations. We therefore generate different kernels for each variant, which all implement the Group-GEMM algorithm but differ in the way they use the group_sizes information to calculate pointer offsets.

The tricky point with a Triton kernel is that each kernel defines the program running on one thread block. Then, the GPU launches a grid of programs (one per output tile); so each program needs to figure out which slice of data it owns, perform the matmul for that slice, and write its output tile. So, what differs between the variants is:

• where the raggedness lives,
• whether group_sizes is loaded at all,
• how the group offset is used.

Note that how these per-tile programs are laid out across the grid is a scheduling decision, not part of the per-program arithmetic above. Two complementary mechanisms shape that layout:

• the M/N-swap heuristic fromThe Compilation Pipeline , which decideswhich grid axis varies slowly so that the smaller per-group operand stays resident in L2; and
• a tile-id remapping in the emitter (specific to the non-contracting/MoE variant), which reorders program IDs so that tiles belonging to thesame group run close together, keeping that group’s RHS weight matrix hot in L2 cache. (Note that this optimization was replicated for theROCm AITER Group-GEMM implementation).

Together these keep each expert’s weights cache-resident while its tiles are being computed.

Non-Contracting (the MoE Case)#

Shape: LHS[M_total, K] × RHS[G, K, N] → out[M_total, N]. The ragged axis is M (the stacked tokens). Every output row m belongs to exactly one group g = group(m), and that group selects which weight matrix RHS[g] is used.

The emitted kernel has (conceptually) this signature:

@triton.jit
def ragged_dot_non_contracting(
    lhs_ptr,          # [M_total, K]  all tokens, stacked in group order
    rhs_ptr,          # [G, K, N]     one weight matrix per group (expert)
    out_ptr,          # [M_total, N]  output, same row layout as lhs
    group_sizes_ptr,  # [G]           rows per group; sum == M_total
    M_total, K, N, G,
    BLOCK_M: tl.constexpr, BLOCK_N: tl.constexpr, BLOCK_K: tl.constexpr,
):
    pid_m = tl.program_id(0)      # which M-tile this program owns
    pid_n = tl.program_id(1)      # which N-tile this program owns
    row_start = pid_m * BLOCK_M   # first LHS row of this tile (in [0, M_total))
    ...

The subtle part of the kernel is to “know” which portion of the data the kernel is expected to compute. Indeed, the program only knows its M-tile position — i.e. which band of BLOCK_M rows of the stacked LHS it is responsible for (row_start = pid_m * BLOCK_M). What it does not directly know is which expert those rows came from, because the group boundaries depend on the runtime group_sizes. To recover the group it runs a prefix sum over group_sizes:

group_sizes         = [ m0, m1,     m2,       … ]
prefix (exclusive)  = [ 0,  m0,     m0+m1,    … ]   # group start rows
prefix (inclusive)  = [ m0, m0+m1,  m0+m1+m2, … ]   # group end rows

The exclusive prefix sum gives the start row of every group; the inclusive one gives the end row. The program’s group g is simply the group whose [start, end) interval contains its row_start — i.e. the largest g such that prefix_exclusive[g] <= row_start. From that same table it reads group_start_row = prefix_exclusive[g], which tells it the offset of its group inside the stacked buffer (needed to address LHS/ out correctly, and to mask the partial tile at the group’s boundary).

Table 2 below works through a tiny example — group_sizes = [3, 2, 4] (so M_total = 9) and BLOCK_M = 3:

Table 2: Worked example of the group lookup for group_sizes = [3, 2, 4] with BLOCK_M = 3.

pid_m	row_start	falls in group g	group_start_row	uses weights
0	0	0 (rows 0–2)	0	RHS[0]
1	3	1 (rows 3–4)	3	RHS[1]
2	6	2 (rows 5–8)	5	RHS[2]

(When a tile straddles a group boundary, the emitter masks the rows outside the group so each row is only ever attributed to a single expert.)

Per program:

1. Compute the prefix sum over group_sizes ; from its own M-tile position (row_start = pid_m * BLOCK_M ) find which groupg it falls into (the group whose[start, end) row interval containsrow_start ) and read that group’s start rowgroup_start_row = prefix_exclusive[g] .
2. Use the group index g to select the matching RHS sliceRHS[g, :, :] , i.e. that expert’s weight matrix.
3. Accumulate a tiled dot product over the contraction dimension K (the usual GEMM inner loop), producing an [BLOCK_M, BLOCK_N] output tile, and write it toout .

group_sizes is loaded — it drives both the group selection and the row offset. Figure 14 summarizes this program flow.

Contracting#

Shape: LHS[M, K_total] × RHS[K_total, N] → out[G, M, N]. The ragged axis is the K (contracted) dimension, and — unlike the non-contracting case — the group index shows up in the output: instead of one contraction over all of K, each group g contributes its own result matrix by reducing only over the slice of the contracted axis that belongs to it.

The emitted kernel has (conceptually) this signature:

@triton.jit
def ragged_dot_contracting(
    lhs_ptr,          # [M, K_total]  contracted axis is ragged
    rhs_ptr,          # [K_total, N]
    out_ptr,          # [G, M, N]     one output matrix per group
    group_sizes_ptr,  # [G]           K-slice size per group; sum == K_total
    M, K_total, N, G,
    BLOCK_M: tl.constexpr, BLOCK_N: tl.constexpr, BLOCK_K: tl.constexpr,
):
    pid_g = tl.program_id(0)      # which group this program owns (→ output slab g)
    pid_m = tl.program_id(1)      # which M-tile
    pid_n = tl.program_id(2)      # which N-tile
    ...

The key structural difference from the non-contracting case is that the group dimension does exist in the output, and that changes how a program finds its group:

• For the non-contracting kernel, the group index does not appear in the output shape — all groups write into the same[M_total, N] buffer, stacked by row. A program is assigned an M-tile (a band of rows) and mustfind out which group those rows belong to by scanning the prefix sum.
• For the contracting kernel, the group index is an output dimension ( out[G, M, N] ). Each group produces its own[M, N] output, so the groups can simply be distributed over the grid. Consequently, XLA makesG aparallel grid axis , and each program is handed its group directly aspid_g .

To illustrate this, Figure 16 shows the same pool of blocks under the two kernels. In the non-contracting case a block is placed by its (M-tile, N-tile) position and only afterwards figures out its group g from the prefix sum — so the group is a runtime label, not a launch coordinate. In the contracting case the G axis is part of the launch grid, so each block is born owning a specific group g = pid_g — the groups are literally spread across blocks by the scheduler.

What the program needs from group_sizes is where along K its group’s slice begins and ends — the ragged K partition is still runtime data. It reads that from the same prefix-sum table:

group_sizes         = [ k0,   k1,      k2,        … ]   # K-rows per group
prefix (exclusive)  = [ 0,    k0,      k0+k1,     … ]   # k_start for each group
prefix (inclusive)  = [ k0,   k0+k1,   k0+k1+k2,  … ]   # k_end   for each group

For its own pid_g, the program reads k_start = prefix_exclusive[pid_g] and k_end = prefix_inclusive[pid_g], then contracts over only [k_start, k_end) of the K axis.

Per program:

1. Take its group g = pid_g from the grid, and readk_start /k_end from the prefix sum overgroup_sizes — this time the offset locates the group’s slice along the contracted axis.
2. Accumulate a partial dot over just that [k_start, k_end) slice of the contracted axis.
3. Write to out[g, :, :] — the output position indexed by the groupg .

group_sizes is loaded: it provides the per-group start/end offsets along K. Figure 17 summarizes this program flow.

Batch#

Shape: LHS[B, M, K] × RHS[B, K, N] → out[B, M, N] — an ordinary batched GEMM. The ragged dimension is a batch dimension, but because every batch element is fully computed there are no data-dependent group offsets to work out: each program simply owns one (batch, M-tile, N-tile) and does a full contraction over K.

The emitted kernel has (conceptually) this signature:

@triton.jit
def ragged_dot_batch(
    lhs_ptr,          # [B, M, K]
    rhs_ptr,          # [B, K, N]
    out_ptr,          # [B, M, N]
    B, M, K, N,
    BLOCK_M: tl.constexpr, BLOCK_N: tl.constexpr, BLOCK_K: tl.constexpr,
):
    pid_b = tl.program_id(0)      # which batch element this program owns
    pid_m = tl.program_id(1)      # which M-tile
    pid_n = tl.program_id(2)      # which N-tile
    ...

Because the batch index pid_b comes straight from the grid and every batch element has the same, statically-known shape, the program can compute all of its pointers from pid_b, pid_m, pid_n and the compile-time strides alone. There is no group boundary to discover, so group_sizes is not even loaded here. It influences scheduling only, but not the arithmetic.

Per program:

1. Take its batch index b = pid_b from the grid (and itspid_m ,pid_n tile positions).
2. Accumulate a tiled dot product over K between LHS[b] andRHS[b] .
3. Write the [BLOCK_M, BLOCK_N] result toout[b, M-tile, N-tile] .

group_sizes is not loaded: it is used only as a scheduling hint. Figure 19 summarizes this program flow.

Autotuning and the group_sizes Seeding Problem#

This backend runs into the very same issue as the hipBLASLt autotuner in Autotuning.

During autotuning, candidate kernels run on synthetic input buffers, which are filled with random bytes by default. That’s harmless for a normal GEMM. But group_sizes is made of control values that determine loop bounds and memory offsets.

The fix mirrors the hipBLASLt one: before profiling, the profiler writes balanced, valid data into the group_sizes buffer — every group gets an equal share of the rows, and the last group absorbs any remainder — guaranteeing the sizes sum exactly to the ragged dimension.

Part 4 — Performance Evaluation# #

Every comparison is made against the padded-dot baseline from The Naive Support, and Why It Hurts: Padded-Dot: the ragged-dot is rewritten into regular dot operations by expanding the ragged input of G groups into G padded matrices, with the associated pre- and post-processing of the input and output matrices. This is the “before” picture that Group-GEMM aims to beat, recalled in Figure 20.

Testbed Characteristics#

The performance evaluations have been performed on two AMD GPU targets, MI300 (gfx942) and MI350 (gfx950). The software configuration was as follows:

• Operating System : Ubuntu 22.04
• ROCm version : 7.2.4
• JAX version : upstream (https://github.com/jax-ml/jax) commit 0eb0f676ba22b15b9dfe29518ab0d40277b7138d
• XLA version : ROCm (https://github.com/ROCm/xla) branch pr/ragged-dot-6-e2e-tests (upstream commit e5d008bb03d9b133b0881daf3d108adea8e6625b + ragged-dot Triton support commits)
• MaxText version : ROCm (https://github.com/ROCm/maxtext) commit fb25ae8c850fa2b57dd5eb7ebfbe399f08534e69

Note that ROCm version 7.2.4 only offers Group-GEMM support for bf16 on MI300. Support for bf16 on MI350 was not yet available when this blog post was written.

The ragged-dot Triton backend is not enabled by default and must be explicitly enabled using the following flag xla_gpu_experimental_triton_ragged_dot=true. Furthermore, note that this backend is only supported with the Triton experimental tiling feature. As a consequence, the flag xla_gpu_experimental_enable_tiling_propagation=true must be set alongside the xla_gpu_experimental_triton_ragged_dot flag. Last, the default Triton autotuning is not yet fine-tuned for ragged-dot, so exhaustive search was used for the evaluation xla_gpu_exhaustive_tiling_search=true.

Use Case: MoE Model Training Using MaxText#

MaxText is a high-performance, highly scalable, open-source LLM library and reference implementation written in Python/JAX. Because it is written on top of JAX, its MoE layers ultimately lower to JAX primitives — and, on the sparse path, to the jax.lax.ragged_dot op that the Group-GEMM backends described above accelerate. This makes MaxText an ideal framework in which to evaluate the new ragged-dot backends on realistic MoE models.

Two MoE Modes: Drop vs. Dropless#

Before diving into how MaxText runs the expert FFNs, it helps to recall that there are two ways of handling the per-expert token counts of an MoE layer — and the choice between them is an accuracy/efficiency trade-off.

• Drop mode. Each expert is given afixed capacityexpert_capacity (expert_capacity = ceil(tokens_per_batch / E) × capacity_factor ). Tokens routed beyond an expert’s capacity are simply dropped (they skip the FFN and contribute nothing), and under-filled experts are padded up toexpert_capacity . This keeps every expert’s matmul a regular, statically-shaped[expert_capacity, K] × [K, N] , which is hardware-friendly, but it wastes FLOPs on the padding of under-filled experts and loses information on the dropped tokens of over-filled ones.
• Dropless mode. No token is ever dropped and no capacity padding is introduced: every routed (token, expert) pair is computed exactly. This preserves the full model quality, but it requires handling theragged , data-dependent per-expert sizes — either by physically gathering tokens per expert into one ragged matmul (the block-sparse formulation introduced byMegaBlocks [Gale et al., 2022] , which is exactly theragged-dot /Group-GEMM path this post is about), or by running a full dense compute over all tokens and masking afterwards.

Figure 21 illustrates the buffers the two modes produce.

The rest of this section looks at how MaxText realizes these two modes through its three concrete compute paths. For a complementary, MaxText-focused deep dive into the dropless MoE path and its optimization, see the AMD ROCm blog Dropless MoE in MaxText.

The Three MoE Compute Paths in MaxText#

Before diving into the models, it is worth noticing that ragged-dot is only one of several ways to run the expert FFNs and combine their outputs. If you look at the MaxText framework, it exposes three distinct MoE compute paths — two of them implement the dropless mode (the sparse / ragged-dot path and the dense mask-and-combine path), while one implements the drop mode (the capacity-based dense dispatch/combine path). The ragged-dot/Group-GEMM work described so far powers just one of the two dropless paths.

All three share the same front-end — a router (gating network) picks, for every token, its top-k experts and a weight per selected expert:

top_k_weights, top_k_indices = jax.lax.top_k(gate_logits, num_experts_per_tok)  # [B, S, k]

However, they differ in the way the selected (token, expert) pairs are turned into matmuls, and in the pre-/post-processing that surrounds those matmuls.

From a user’s point of view, two config knobs allow choosing the path:

• sparse_matmul —True picks the sparse (ragged-dot) path (the dropless, block-sparse formulation of the MoE computation);False picks one of the two dense paths.
• capacity_factor — inside the dense path,> 0 enables token dropping (fixed per-expert capacity);<= 0 keeps it dropless.

Figure 22 shows how these two knobs select a path.

Table 3 summarizes the trade-offs before we look at each path in detail:

Table 3: The three MaxText MoE compute paths and their trade-offs.

	Path 1 — Sparse (ragged-dot)	Path 2 — Dense dropless	Path 3 — Dense drop
config	sparse_matmul = True	sparse_matmul = False ,capacity_factor ≤ 0	sparse_matmul = False ,capacity_factor > 0
expert op	jax.lax.ragged_dot	dense per-expert einsum over all tokens	dense capacity-padded batched einsum
pre-processing	permute (sort tokens by expert) + bincount group sizes	none (broadcast all tokens to all experts)	build dispatch mask (one-hot into capacity slots), drop overflow
post-processing	un-permute (scatter back) + weighted sum	weighted combine (BSEM,BSE→BSM ), zeros non-selected	combine mask gathers from capacity slots back to tokens
compute cost	≈ M × K × N (only routed rows)	≈ E × (B·S) × K × N (every token × every expert )	≈ E × C × K × N (C = capacity)
drops tokens?	no	no	yes (overflow beyond C )
padding	none	none (but full dense compute)	per-expert capacity padding

Path 1 — Sparse / Ragged-Dot (Dropless)#

Selected by sparse_matmul = True. This is the path that generates jax.lax.ragged_dot ops which are then lowered by XLA. The idea is to physically gather the tokens by expert so that the expert FFNs become one big ragged matmul.

Pre-processing — permute. The router’s top_k_indices are used to sort all M = B·S·top_k token-copies into contiguous per-expert groups, and a bincount produces the group_sizes vector (real routed counts, summing to M):

sorted_selected_experts = jnp.argsort(jnp.ravel(selected_experts))
sorted_inputs = _sort_activations(replicated_inputs, sorted_selected_experts)  # [M, K]
group_sizes  = jnp.bincount(jnp.ravel(selected_experts), length=num_experts)   # [E], sums to M

Compute — Group-GEMM. The gathered tokens and the per-expert weights feed directly into jax.lax.ragged_dot, which can be later lowered to hipBLASLt / Triton Group-GEMM by XLA.

out = jax.lax.ragged_dot(lhs=sorted_inputs,        # [M, K]  tokens, grouped by expert
                         rhs=w,                     # [E, K, N] expert weights
                         group_sizes=group_sizes,   # [E]
                         preferred_element_type=dtype)

Post-processing — un-permute. The results are scattered back to the original token order and the top-k contributions are summed with the router weights:

unsorted = _sort_activations(out, jnp.argsort(sorted_selected_experts))
output   = jnp.einsum("BKE,BK -> BE", unsorted.reshape(-1, top_k, N), top_k_weights)

The whole path is summarized in Figure 23.

Cost: only the real routed rows are ever multiplied — compute is ≈ M × K × N with no padding and no dropping. So, regarding the matrix multiplication itself, this path with Group-GEMM backends provides the most efficient solution. However, we have to pay for the sort/scatter (permute/un-permute) which is needed to put the data in a form that can be processed by the Group-GEMM backends.

Path 2 — Dense Dropless (Mask-and-Combine)#

Selected by sparse_matmul = False and capacity_factor ≤ 0. In this path, there is no gather at all: every token is sent through every expert, and the router weights (zero for non-selected experts) mask out the unwanted results at the end.

Pre-processing — none (beyond turning top-k into a dense [B,S,E] weight matrix, 0 where an expert was not selected):

weights = reshape_and_update_weights(top_k_weights, top_k_indices)  # [B,S,E], 0 off-selection

Compute — full dense einsums. Each expert processes the entire token batch:

layer_w0 = jnp.einsum("BSM,EMH -> BSEH", inputs, w0_kernel)   # [B,S,E,H]
layer_w1 = jnp.einsum("BSM,EMH -> BSEH", inputs, w1_kernel)
inter    = activation(layer_w0) * layer_w1
inter    = jnp.einsum("BSEH,EHM -> BSEM", inter, wo_kernel)   # [B,S,E,M]

Post-processing — weighted combine. The router weights collapse the expert axis, keeping only each token’s selected experts:

output = jnp.einsum("BSEM,BSE -> BSM", inter, weights)        # [B,S,M]

The whole path is summarized in Figure 24.

Cost: dropless and permutation-free, but compute is ≈ E × (B·S) × K × N — every token pays for every expert, so it scales with the full expert count. This is simple and hardware-friendly (plain dense matmuls, no ragged handling) but becomes prohibitively expensive as E grows.

Path 3 — Dense Drop (Capacity Dispatch/Combine)#

Selected by sparse_matmul = False and capacity_factor > 0. This is the classic fixed-capacity MoE: each expert gets a static slot of C = ceil(tokens_per_batch / E) × capacity_factor rows; tokens beyond C are dropped.

Pre-processing — dispatch mask (with dropping). generate_masks builds a one-hot dispatch_mask that assigns each kept (token, expert) pair to a capacity slot and truncates any overflow:

expert_capacity = ceil(tokens_per_batch / num_experts) * capacity_factor
dispatch_mask, combine_mask = generate_masks(top_k_indices, weights)

Compute — capacity-padded batched einsum. Tokens are scattered into the [E, B, C, M] capacity buffer, run through the experts, and the result stays in capacity layout:

dispatch = jnp.einsum("BSM,BSEC -> EBCM", inputs, dispatch_mask)     # scatter to slots
layer_w0 = jnp.einsum("EBCM,EMH -> EBCH", dispatch, w0_kernel)       # up/gate
inter    = activation(layer_w0) * jnp.einsum("EBCM,EMH -> EBCH", dispatch, w1_kernel)
inter    = jnp.einsum("EBCH,EHM -> EBCM", inter, wo_kernel)          # down

Post-processing — combine mask. The combine_mask gathers each token’s outputs back from its capacity slots and applies the router weights:

output = jnp.einsum("EBCM,BSEC -> BSM", inter, combine_mask)          # gather back to tokens

The whole path is summarized in Figure 25.

Cost: compute is ≈ E × C × K × N. Because C is fixed, under-filled experts waste FLOPs on padding rows and over-filled experts drop tokens (an accuracy trade-off). The capacity buffer also inflates the activation memory.

What About Performance?#

In theory, the ragged-dot/Group-GEMM path:

• vs. Path 2 (dense dropless) — Group-GEMM computes only the routed rows ( M × K × N ) instead of every-token-times-every-expert (E × B·S × K × N ), so it wins by a factor that grows with the number of experts — at the cost of the permute/un-permute sort.
• vs. Path 3 (dense drop) — Group-GEMM needs no capacity, no padding, and drops no tokens: it consumes the compact [M, K] layout with realgroup_sizes , avoiding both the wasted-padding FLOPs and the accuracy hit of dropping, while also using less activation memory.

In other words, Group-GEMM keeps the dropless quality of Path 2 with a compute/memory profile close to the ideal (only real work, no padding), trading it for a sort and a ragged-aware kernel. But the remaining question is: how fast is the Group-GEMM kernel itself compared to these dense alternatives on real hardware?

MaxText Models#

We evaluated the performance improvement achieved by the new ragged-dot backends using MaxText MoE models. The evaluated models are described below, and their configurations are given in Table 4 (MI300) and Table 5 (MI350):

“Routing-heavy” vs. “compute-heavy”: each MoE layer spends time on (a) the expert GEMM itself (ragged_dot, ≈ M[tokens] × K[emb] × N[moe_mlp]) and (b) routing — gating top-k selection plus the token permute/sort/scatter that builds the num_experts ragged groups and the un-permute afterwards. A config is routing-heavy when (b) dominates: this happens with small base_moe_mlp_dim (N) (each expert GEMM does little arithmetic) and/or many experts (more small groups → more launch + scatter/gather overhead, lower per-group occupancy). The opposite corner — large N, few experts — is compute-heavy (big dense expert GEMMs dominate, routing negligible).

mixtral-8x7b (MI300 & MI350) — The baseline dense-attention MoE microbenchmark (emb 6144, 24 layers, 32 experts top-4, dot_product attention, no MLA). Used to profile the raw ragged-dot expert GEMM without MLA complexity, at 8-way FSDP, seq 3072, grad-accum 1. The MI300 and MI350 configurations have identical shapes. It is the primary knob-sweep model for tile sizes and backend (hipBLASLt vs. Triton vs. the default baseline).

mixtral-8x7b-large (MI300 & MI350) — A deliberately enlarged mixtral variant (emb/K 8192, moe_mlp/N 28672, 32 layers, 64 experts top-8) that grows both the expert-GEMM K/N dims and the number of ragged groups. Runs 8-way FSDP at seq 4096, grad-accum 8. It is the compute-heavy corner of the sweep — big, dense expert GEMMs with many groups — used to measure ragged-dot throughput at high arithmetic intensity and to check that larger tiles fit within HBM (192 GB HBM3 / 288 GB HBM3e).

deepseek2-16b (MI300 & MI350) — A scaled-down DeepSeek-V2 test (emb 2048, 27 layers, 64 experts top-6, 2 shared experts) that keeps the real MLA attention and deepseek decoder block. It validates the ragged-dot + MLA + YARN-RoPE code path cheaply, running autodetected FSDP, grad-accum 4, seq 512. Shared experts add a dense side-path alongside the routed experts, exercising the mixed dense/sparse MLP.

deepseek3-test (MI300 & MI350) — A tiny DeepSeek-V3 CI proxy (emb 512) that keeps the deepseek block + MLA attention but shrinks everything else. On MI300 it is cut to 16 layers / 32 experts (dense mlp 4096); on MI350 it retains the full 61-layer / 256-expert topology with the tiny emb 512. Runs autodetected FSDP, grad-accum 4, seq 512 — a fast functional check of the ragged-dot + MLA path rather than a perf run.

deepseek3-671b-reduced (MI300 & MI350) — A perf-representative slice of the flagship 671B DeepSeek-V3: it preserves the real expert-GEMM shapes (K/emb 7168, N/moe_mlp 2048, MLA) but cuts to 4 layers / 32 experts so it fits on 8 GPUs. Because FSDP can’t hold the full model it is expert-parallel (EP=8, 4 experts/GPU, FSDP off), grad-accum 8, seq 512. This makes the per-expert GEMM timing representative of the true 671B while keeping the run tractable.

gemma4-26b (MI300 only) — Gemma-4 26B MoE (emb 2816, 30 layers, 128 experts top-8, 1 shared) with the gemma4 decoder block and standard dot_product attention. Small base_moe_mlp_dim (704) means many narrow expert GEMMs, stressing per-group launch/routing overhead rather than raw FLOPs. Runs autodetected FSDP, seq 1024, grad-accum 4 — a good test for many-small-experts ragged-dot efficiency on the 192 GB HBM3 gfx942 platform.

qwen3-30b-a3b (MI300 & MI350) — Qwen3 MoE (emb 2048, 48 layers, 128 experts top-8, qwen3_moe block, QK-norm) with a very small expert width (base_moe_mlp_dim 768). Like gemma4 it is dominated by many thin expert GEMMs and routing overhead rather than arithmetic intensity. MI300 and MI350 use identical shapes (autodetected FSDP, seq 1024, grad-accum 4). A lightweight but routing-heavy ragged-dot workload.

qwen3-235b-a22b (MI350 only) — Large Qwen3 MoE (emb 4096, 94 layers, 128 experts top-8, moe_mlp 1536). The deep 94-layer stack combined with 128 experts makes it the heaviest routing/attention workload in the tables; it runs 8-way FSDP, seq 2048, grad-accum 16. Sequence length and layer depth push activation memory, so remat and FSDP are essential to fit — a scale/depth stress test for ragged-dot.

llama4-17b-16e (MI350 only) — Llama-4 17B, 16-expert, top-1 routing (each token → a single expert) with wide experts (moe_mlp 8192) and a shared expert. This combination makes it the compute-heavy corner: a few large, dense expert GEMMs where the padded-dot baseline already wastes little, so Group-GEMM has limited headroom to improve on it. Runs autodetected FSDP, seq 1024, grad-accum 4.

MI300 (MI300X, gfx942, 192 GB HBM3, 8× GPU)#

Table 4: MaxText MoE model configurations evaluated on MI300.

Model (config)	emb_dim (K)	moe_mlp_dim (N)	mlp_dim	layers	experts	top-k	shared	attn	seq len	grad-accum	parallelism (FSDP / EP / TP)
mixtral-8x7b	6144	20480	20480	24	32	4	–	dot	3072	1	8 / 1 / 1
mixtral-8x7b-large	8192	28672	28672	32	64	8	–	dot	4096	8	8 / 1 / 1
deepseek2-16b	2048	1408	5632	27	64	6	2	MLA	512	4	auto / 1 / 1
deepseek3-test	512	512	4096	16	32	8	1	MLA	512	4	auto / 1 / 1
deepseek3-671b-reduced	7168	2048	18432	4	32	8	1	MLA	512	8	1 / 8 / 1
gemma4-26b	2816	704	2112	30	128	8	1	dot	1024	4	auto / 1 / 1
qwen3-30b-a3b	2048	768	768	48	128	8	–	dot	1024	4	auto / 1 / 1

MI350-Class (gfx950, 288 GB HBM3e, 8× GPU)#

Table 5: MaxText MoE model configurations evaluated on MI350.

Model (config)	emb_dim (K)	moe_mlp_dim (N)	mlp_dim	layers	experts	top-k	shared	attn	seq len	grad-accum	parallelism (FSDP / EP / TP)
mixtral-8x7b	6144	20480	20480	24	32	4	–	dot	3072	1	8 / 1 / 1
mixtral-8x7b-large	8192	28672	28672	32	64	8	–	dot	4096	8	8 / 1 / 1
deepseek2-16b	2048	1408	5632	27	64	6	2	MLA	512	4	auto / 1 / 1
deepseek3-test	512	512	18432	61	256	8	1	MLA	512	4	auto / 1 / 1
deepseek3-671b-reduced	7168	2048	18432	4	32	8	1	MLA	512	8	1 / 8 / 1
qwen3-30b-a3b	2048	768	768	48	128	8	–	dot	1024	4	auto / 1 / 1
qwen3-235b-a22b	4096	1536	1536	94	128	8	–	dot	2048	16	8 / 1 / 1
llama4-17b-16e	5120	8192	8192	48	16	1	1	dot	1024	4	auto / 1 / 1

Legend:

• emb_dim (K) = expert-GEMM contraction dim
• moe_mlp_dim (N) = expert-GEMM output dim
• attn = attention type (MLA = Multi-head Latent Attention — DeepSeek’s low-rank compressed KV attention)
• parallelism =ici_fsdp_parallelism / ici_expert_parallelism / ici_tensor_parallelism , i.e.FSDP (Fully Sharded Data Parallel — params/grads/optimizer sharded across GPUs) /EP (Expert Parallel — MoE experts distributed across GPUs) /TP (Tensor Parallel — individual matmuls split across GPUs)
• auto =-1 (autodetects available GPUs).

Micro-Benchmark#

In order to evaluate the performance increase provided by the new backends for the ragged-dot operations, we isolated the ragged-dot operations executed in the MaxText models mentioned above and created a synthetic micro-benchmark that “replays” these operations alone. This micro-benchmark is written at the JAX level (so it evaluates the whole compilation pipeline), runs the identified ragged-dot ops 50 times (after a 10-run warm-up), and calculates the average execution time over these 50 runs. As the hipBLASLt Group-GEMM backend is only available for the bf16 datatype on MI300, we chose to show only numbers for this target in this blog post.

From an MoE Layer to 6 Ragged-Dot Classes#

An MoE expert block in MaxText is built from two projections — an up/gate projection (wi) and a down projection ( wo) — and each of those has to be differentiated, producing a data gradient (dgrad) and a weight gradient (wgrad) in the backward pass.

When you enumerate every ragged-dot XLA emits across the forward + backward pass, they collapse into exactly 6 structural classes. Two operations belong to the same class if and only if their operands share the same rank (number of dimensions) and the same contracting / ragged / group dimension numbers, and the output has the same rank and layout. However, the sizes (M, K, N, E) may differ.

In the following, we use the notation given in Table 6:

Table 6: Notation used to describe the ragged-dot classes.

symbol	meaning
M	ragged token dimension = batch × seq × top_k (the real routed-token count; no capacity padding on theragged_dot path)
K	expert-GEMM contraction / embedding dim (base_emb_dim )
N	expert-GEMM output dim (base_moe_mlp_dim )
E	number of experts (num_experts )
group_sizes	int32[E] , per-expert token counts, summing toM

The M (token) axis is the ragged axis: it is partitioned into E groups, one per expert, and dtype is bfloat16 throughout. The six classes are listed in Table 7:

Table 7: The six structural ragged-dot classes emitted across the forward and backward pass.

class	role	lhs	rhs	out	contract (lhs,rhs)	rhs_group
fwd_wi	fwd gate/up	[M,K]	[E,K,N]	[M,N]	{1},{1}	{0}
fwd_wo	fwd down	[M,N]	[E,N,K]	[M,K]	{1},{1}	{0}
dgrad_wi	dgrad up	[M,N]	[E,K,N]	[M,K]	{1},{2}	{0}
dgrad_wo	dgrad down	[M,K]	[E,N,K]	[M,N]	{1},{2}	{0}
wgrad_wi	wgrad up	[M,K]	[M,N]	[E,K,N]	{0},{0}	{} (empty)
wgrad_wo	wgrad down	[M,N]	[M,K]	[E,N,K]	{0},{0}	{} (empty)

All classes are bfloat16, with lhs_ragged_dimensions = {0} and group_sizes = int32[E].

• The forward classes (fwd_wi ,fwd_wo ) are the plainjax.lax.ragged_dot form —inputs[M,K] × w[E,K,N] → out[M,N] for the gate/up projection, andinterm[M,N] × w[E,N,K] → out[M,K] for the down projection.
• The dgrad classes (dgrad_wi ,dgrad_wo ) contract the weight’soutput-feature axis (rhs_contracting = {2} ), so they require the explicitragged_dot_general form with custom dimension numbers.
• The wgrad classes (wgrad_wi ,wgrad_wo ) are[M,·] × [M,·] → [E,·,·] Group-GEMMs that contract the ragged token axis and produce one weight-gradient slab per expert (emptyrhs_group_dimensions ).

For example, fwd_wi — the gate/up projection — is simply:

import jax.numpy as jnp
from jax import lax

lhs = jnp.zeros((M, K), jnp.bfloat16)          # tokens
rhs = jnp.zeros((E, K, N), jnp.bfloat16)       # expert weights
out = lax.ragged_dot(lhs, rhs, group_sizes,    # -> [M, N]
                     preferred_element_type=jnp.bfloat16)

while a weight-gradient such as wgrad_wi needs the general form with explicit dimension numbers:

wgrad_dn = lax.RaggedDotDimensionNumbers(
    dot_dimension_numbers=(((0,), (0,)), ((), ())),
    lhs_ragged_dimensions=(0,),
    rhs_group_dimensions=(),        # empty -> grouped output on E
)
out = lax.ragged_dot_general(lhs, rhs, group_sizes,   # -> [E, K, N]
                             ragged_dot_dimension_numbers=wgrad_dn,
                             preferred_element_type=jnp.bfloat16)

Fixing group_sizes Deterministically#

In real training the per-expert token counts are data-dependent — they come out of the router and change every step. For a reproducible benchmark we instead use a balanced / uniform partition: every expert receives M // E tokens, and the remainder M mod E is spread one extra token per group across the first M mod E experts, so that sum(group_sizes) == M exactly:

base = M // E                      # tokens per expert (floor)
rem  = M - base * E                # leftover to distribute (0 <= rem < E)
gs = np.full((E,), base, np.int32)
gs[:rem] += 1                      # first `rem` experts get one extra
group_sizes = jnp.asarray(gs)      # int32[E], sums to M

This gives each expert ≈ M/E rows. Real routing is typically less balanced, which tends to lower the achieved TFLOP/s for the per-group backends.

Results#

For each model variant we measure the runtime of all the 6 classes on each backend (default padded-dot baseline, triton, and hip). The resulting speedups over the baseline are shown in Figure 26.

The full per-class TFLOP/s results for every measured shape are provided in Table 12 of the Appendix: Micro-Benchmark Full Results.

Performance of MaxText MoE Models#

Performance#

Now, let’s consider the overall performance improvement for the whole model train step. Note that in this section, the shown performance is the median value over training steps 5 to 10. The results are reported in Figure 27 and Table 8 for MI300, and in Figure 28 and Table 9 for MI350.

MI300#

Table 8: MaxText MoE model training-step performance on MI300.

Model	Emb Dim	Experts	Exp/Tok	Layers	total_weights	Backend	execution time (s)	TFLOP/s/device	Tokens/s/device	Speedup
deepseek2-16b	2048	64	6	27	15.706B	default	3.946	7.744	519.018	1.00x
deepseek2-16b	2048	64	6	27	15.706B	triton	1.867	16.369	1097.136	2.11x
deepseek2-16b	2048	64	6	27	15.706B	hip	1.761	17.348	1162.700	2.24x
deepseek2-16b	2048	64	6	27	15.706B	dense_matrix	1.617	18.895	1266.397	2.44x
deepseek2-16b	2048	64	6	27	15.706B	dense_matrix_dropless	2.018	15.143	1014.919	1.96x
deepseek3-test	512	256	8	61	15.851B	default	5.758	10.910	355.653	1.00x
deepseek3-test	512	256	8	61	15.851B	triton	2.732	22.995	749.610	2.11x
deepseek3-test	512	256	8	61	15.851B	hip	2.373	26.470	862.896	2.43x
deepseek3-test	512	256	8	61	15.851B	dense_matrix	2.261	27.780	905.610	2.55x
deepseek3-test	512	256	8	61	15.851B	dense_matrix_dropless	2.806	22.387	729.808	2.05x
deepseek3-671b	7168	32	8	4	7.415B	default	0.575	141.236	7126.279	1.00x
deepseek3-671b	7168	32	8	4	7.415B	triton	0.436	186.151	9392.514	1.32x
deepseek3-671b	7168	32	8	4	7.415B	hip	0.429	189.228	9547.763	1.34x
deepseek3-671b	7168	32	8	4	7.415B	dense_matrix	0.414	196.070	9893.003	1.39x
deepseek3-671b	7168	32	8	4	7.415B	dense_matrix_dropless	0.305	265.880	13415.345	1.89x
gemma4-26b	2816	128	8	30	25.233B	default	20.531	4.751	199.507	1.00x
gemma4-26b	2816	128	8	30	25.233B	triton	3.257	29.950	1257.783	6.30x
gemma4-26b	2816	128	8	30	25.233B	hip	3.073	31.737	1332.846	6.68x
gemma4-26b	2816	128	8	30	25.233B	dense_matrix	2.914	33.474	1405.770	7.05x
gemma4-26b	2816	128	8	30	25.233B	dense_matrix_dropless	4.163	23.430	983.947	4.93x
qwen3-30b-a3b	2048	128	8	48	30.532B	default	20.676	3.855	198.105	1.00x
qwen3-30b-a3b	2048	128	8	48	30.532B	triton	5.013	15.897	817.004	4.12x
qwen3-30b-a3b	2048	128	8	48	30.532B	hip	3.505	22.740	1168.655	5.90x
qwen3-30b-a3b	2048	128	8	48	30.532B	dense_matrix	3.287	24.246	1246.054	6.29x
qwen3-30b-a3b	2048	128	8	48	30.532B	dense_matrix_dropless	4.896	16.278	836.600	4.22x
mixtral-8x7b	4096	8	2	32	46.703B	default	5.044	48.057	609.025	1.00x
mixtral-8x7b	4096	8	2	32	46.703B	triton	2.817	86.045	1090.451	1.79x
mixtral-8x7b	4096	8	2	32	46.703B	hip	2.128	113.903	1443.498	2.37x
mixtral-8x7b	4096	8	2	32	46.703B	dense_matrix	2.015	120.291	1524.461	2.50x
mixtral-8x7b	4096	8	2	32	46.703B	dense_matrix_dropless	3.405	71.187	902.164	1.48x
mixtral-8x7b (large)	4096	8	2	32	46.703B	default	52.107	50.128	628.859	1.00x
mixtral-8x7b (large)	4096	8	2	32	46.703B	triton	30.822	84.744	1063.120	1.69x
mixtral-8x7b (large)	4096	8	2	32	46.703B	hip	22.940	113.863	1428.421	2.27x
mixtral-8x7b (large)	4096	8	2	32	46.703B	dense_matrix	18.438	141.662	1777.156	2.83x
mixtral-8x7b (large)	4096	8	2	32	46.703B	dense_matrix_dropless	34.163	76.458	959.171	1.53x

MI350#

Table 9: MaxText MoE model training-step performance on MI350.

Model	Emb Dim	Experts	Exp/Tok	Layers	total_weights	Backend	execution time (s)	TFLOP/s/device	Tokens/s/device	Speedup
deepseek2-16b	2048	64	6	27	15.706B	default	2.581	11.840	793.547	1.00x
deepseek2-16b	2048	64	6	27	15.706B	triton	1.433	21.316	1428.675	1.80x
deepseek2-16b	2048	64	6	27	15.706B	dense_matrix	1.303	23.451	1571.765	1.98x
deepseek2-16b	2048	64	6	27	15.706B	dense_matrix_dropless	1.414	21.603	1447.888	1.83x
deepseek3-test	512	256	8	61	15.851B	default	4.208	14.929	486.677	1.00x
deepseek3-test	512	256	8	61	15.851B	triton	2.220	28.302	922.617	1.90x
deepseek3-test	512	256	8	61	15.851B	dense_matrix	1.778	35.344	1152.180	2.37x
deepseek3-test	512	256	8	61	15.851B	dense_matrix_dropless	1.984	31.662	1032.149	2.12x
deepseek3-671b	7168	32	8	4	7.415B	default	0.459	176.907	8926.120	1.00x
deepseek3-671b	7168	32	8	4	7.415B	triton	0.374	216.782	10938.067	1.23x
deepseek3-671b	7168	32	8	4	7.415B	dense_matrix	0.305	266.230	13433.032	1.50x
deepseek3-671b	7168	32	8	4	7.415B	dense_matrix_dropless	0.188	432.514	21823.103	2.44x
llama4-17b-16e	5120	16	1	48	107.770B	default	10.249	39.299	399.631	1.00x
llama4-17b-16e	5120	16	1	48	107.770B	triton	10.157	39.655	403.258	1.01x
llama4-17b-16e	5120	16	1	48	107.770B	dense_matrix	9.337	43.138	438.671	1.10x
llama4-17b-16e	5120	16	1	48	107.770B	dense_matrix_dropless	9.344	43.108	438.372	1.10x
qwen3-235b-a22b	4096	128	8	4	11.196B	default	22.025	14.110	1487.731	1.00x
qwen3-235b-a22b	4096	128	8	4	11.196B	triton	4.082	76.132	8027.089	5.40x
qwen3-235b-a22b	4096	128	8	4	11.196B	dense_matrix	3.623	85.785	9044.923	6.08x
qwen3-235b-a22b	4096	128	8	4	11.196B	dense_matrix_dropless	5.322	58.391	6156.577	4.14x
qwen3-30b-a3b	2048	128	8	48	30.532B	default	9.696	8.220	422.434	1.00x
qwen3-30b-a3b	2048	128	8	48	30.532B	triton	4.012	19.863	1020.834	2.42x
qwen3-30b-a3b	2048	128	8	48	30.532B	dense_matrix	2.557	31.166	1601.701	3.79x
qwen3-30b-a3b	2048	128	8	48	30.532B	dense_matrix_dropless	3.294	24.197	1243.551	2.94x
mixtral-8x7b	4096	8	2	32	46.703B	default	2.863	84.681	1073.164	1.00x
mixtral-8x7b	4096	8	2	32	46.703B	triton	1.917	126.458	1602.606	1.49x
mixtral-8x7b	4096	8	2	32	46.703B	dense_matrix	1.432	169.318	2145.780	2.00x
mixtral-8x7b	4096	8	2	32	46.703B	dense_matrix_dropless	2.075	116.814	1480.395	1.38x
mixtral-8x7b (large)	4096	8	2	32	46.703B	default	29.188	89.489	1122.641	1.00x
mixtral-8x7b (large)	4096	8	2	32	46.703B	triton	21.327	122.475	1536.450	1.37x
mixtral-8x7b (large)	4096	8	2	32	46.703B	dense_matrix	13.376	195.272	2449.693	2.18x
mixtral-8x7b (large)	4096	8	2	32	46.703B	dense_matrix_dropless	25.522	102.344	1283.910	1.14x

The performance numbers confirm that the new Group-GEMM based backends for jax.lax.ragged_dot operations provide a significant speedup for MoE models. As expected, the hipBLASLt backend is faster than the Triton one; however, both offer very interesting speedups. That said, we also notice that the dense matrix (drop case) approach outperforms the ragged-dot path for all the tested models. Indeed, as GPUs are optimized for regular computation, the pure matrix multiplication was expected to be faster than Group-GEMM. However, we might have expected that the extra computation due to the padding would result in a larger slowdown, making the ragged-dot approach faster. But this is not the case, for two main reasons:

the capacity is relatively low (1.25), which means that the padding is relatively small, but potentially a significant number of tokens could be dropped;

the pre-processing to put the data in shape for the ragged-dot backend is expensive. Consequently, for the relatively small models evaluated, the time overhead introduced by the pre-processing cancels out the benefit of the Group-GEMM performing only useful multiplications. But with larger models the pre-processing overhead could be better balanced against the matmul efficiency, making the ragged-dot Group-GEMM backends attractive.

Memory Savings#

The memory-usage figures below were extracted directly from the log traces emitted by MaxText during each training run. MaxText reports, per run, the peak device memory footprint (broken down into total and temporary/scratch memory), which we collected for each backend (default, triton, hip) and diffed against the default padded-dot baseline to obtain the savings shown. They are reported in Figure 29 and Table 10 for MI300, and in Figure 30 and Table 11 for MI350.

MI300#

Table 10: MaxText MoE model peak memory footprint on MI300.

Model	Emb Dim	Experts	Exp/Tok	Layers	total_weights	Backend	Total Mem (GB)	Temp Mem (GB)	Mem Savings (GB)	Temp Savings (GB)
deepseek2-16b	2048	64	6	27	15.706B	default	26.7	15.7	0.0 (0.0%)	0.0 (0.0%)
deepseek2-16b	2048	64	6	27	15.706B	triton	23.6	12.6	3.1 (11.6%)	3.1 (19.7%)
deepseek2-16b	2048	64	6	27	15.706B	hip	23.6	12.6	3.1 (11.6%)	3.1 (19.7%)
deepseek2-16b	2048	64	6	27	15.706B	dense_matrix (capacity 1.25)	23.4	12.5	3.3 (12.4%)	3.2 (20.4%)
deepseek2-16b	2048	64	6	27	15.706B	dense_matrix_dropless	23.9	13.0	2.8 (10.5%)	2.7 (17.2%)
deepseek3-test	512	256	8	61	15.851B	default	26.3	15.2	0.0 (0.0%)	0.0 (0.0%)
deepseek3-test	512	256	8	61	15.851B	triton	23.1	12.0	3.2 (12.2%)	3.2 (21.1%)
deepseek3-test	512	256	8	61	15.851B	hip	23.1	12.0	3.2 (12.2%)	3.2 (21.1%)
deepseek3-test	512	256	8	61	15.851B	dense_matrix (capacity 1.25)	23.1	12.0	3.2 (12.2%)	3.2 (21.1%)
deepseek3-test	512	256	8	61	15.851B	dense_matrix_dropless	23.6	12.6	2.7 (10.3%)	2.6 (17.1%)
deepseek3-671b	7168	32	8	4	7.415B	default	8.6	3.4	0.0 (0.0%)	0.0 (0.0%)
deepseek3-671b	7168	32	8	4	7.415B	triton	8.6	3.4	0.0 (0.0%)	0.0 (0.0%)
deepseek3-671b	7168	32	8	4	7.415B	hip	8.6	3.4	0.0 (0.0%)	0.0 (0.0%)
deepseek3-671b	7168	32	8	4	7.415B	dense_matrix (capacity 1.25)	8.5	3.4	0.1 (1.2%)	0.0 (0.0%)
deepseek3-671b	7168	32	8	4	7.415B	dense_matrix_dropless	8.5	3.4	0.1 (1.2%)	0.0 (0.0%)
gemma4-26b	2816	128	8	30	25.233B	default	61.0	43.3	0.0 (0.0%)	0.0 (0.0%)
gemma4-26b	2816	128	8	30	25.233B	triton	43.6	26.0	17.4 (28.5%)	17.3 (40.0%)
gemma4-26b	2816	128	8	30	25.233B	hip	43.6	26.0	17.4 (28.5%)	17.3 (40.0%)
gemma4-26b	2816	128	8	30	25.233B	dense_matrix (capacity 1.25)	40.0	22.3	21.0 (34.4%)	21.0 (48.5%)
gemma4-26b	2816	128	8	30	25.233B	dense_matrix_dropless	41.6	23.9	19.4 (31.8%)	19.4 (44.8%)
qwen3-30b-a3b	2048	128	8	48	30.532B	default	57.7	36.4	0.0 (0.0%)	0.0 (0.0%)
qwen3-30b-a3b	2048	128	8	48	30.532B	triton	44.5	23.2	13.2 (22.9%)	13.2 (36.3%)
qwen3-30b-a3b	2048	128	8	48	30.532B	hip	44.5	23.2	13.2 (22.9%)	13.2 (36.3%)
qwen3-30b-a3b	2048	128	8	48	30.532B	dense_matrix (capacity 1.25)	44.5	23.2	13.2 (22.9%)	13.2 (36.3%)
qwen3-30b-a3b	2048	128	8	48	30.532B	dense_matrix_dropless	45.8	24.5	11.9 (20.6%)	11.9 (32.7%)
mixtral-8x7b	4096	8	2	32	46.703B	default	120.2	54.9	0.0 (0.0%)	0.0 (0.0%)
mixtral-8x7b	4096	8	2	32	46.703B	triton	114.4	49.1	5.8 (4.8%)	5.8 (10.6%)
mixtral-8x7b	4096	8	2	32	46.703B	hip	114.7	49.5	5.5 (4.6%)	5.4 (9.8%)
mixtral-8x7b	4096	8	2	32	46.703B	dense_matrix (capacity 1.25)	115.0	49.7	5.2 (4.3%)	5.2 (9.5%)
mixtral-8x7b	4096	8	2	32	46.703B	dense_matrix_dropless	117.7	52.5	2.5 (2.1%)	2.4 (4.4%)
mixtral-8x7b (large)	4096	8	2	32	46.703B	default	79.9	47.2	0.0 (0.0%)	0.0 (0.0%)
mixtral-8x7b (large)	4096	8	2	32	46.703B	triton	72.7	40.1	7.2 (9.0%)	7.1 (15.0%)
mixtral-8x7b (large)	4096	8	2	32	46.703B	hip	72.9	40.2	7.0 (8.8%)	7.0 (14.8%)
mixtral-8x7b (large)	4096	8	2	32	46.703B	dense_matrix (capacity 1.25)	73.3	40.7	6.6 (8.3%)	6.5 (13.8%)
mixtral-8x7b (large)	4096	8	2	32	46.703B	dense_matrix_dropless	77.0	44.4	2.9 (3.6%)	2.8 (5.9%)

MI350#

Table 11: MaxText MoE model peak memory footprint on MI350.

Model	Emb Dim	Experts	Exp/Tok	Layers	total_weights	Backend	Total Mem (GB)	Temp Mem (GB)	Mem Savings (GB)	Temp Savings (GB)
deepseek2-16b	2048	64	6	27	15.706B	default	26.7	15.7	0.0 (0.0%)	0.0 (0.0%)
deepseek2-16b	2048	64	6	27	15.706B	triton	23.7	12.7	3.0 (11.2%)	3.0 (19.1%)
deepseek2-16b	2048	64	6	27	15.706B	dense_matrix (capacity 1.25)	23.5	12.5	3.2 (12.0%)	3.2 (20.4%)
deepseek2-16b	2048	64	6	27	15.706B	dense_matrix_dropless	23.9	13.0	2.8 (10.5%)	2.7 (17.2%)
deepseek3-test	512	256	8	61	15.851B	default	26.3	15.2	0.0 (0.0%)	0.0 (0.0%)
deepseek3-test	512	256	8	61	15.851B	triton	23.2	12.2	3.1 (11.8%)	3.0 (19.7%)
deepseek3-test	512	256	8	61	15.851B	dense_matrix (capacity 1.25)	23.2	12.1	3.1 (11.8%)	3.1 (20.4%)
deepseek3-test	512	256	8	61	15.851B	dense_matrix_dropless	23.8	12.8	2.5 (9.5%)	2.4 (15.8%)
deepseek3-671b	7168	32	8	4	7.415B	default	8.6	3.4	0.0 (0.0%)	0.0 (0.0%)
deepseek3-671b	7168	32	8	4	7.415B	triton	8.6	3.4	0.0 (0.0%)	0.0 (0.0%)
deepseek3-671b	7168	32	8	4	7.415B	dense_matrix (capacity 1.25)	9.7	4.5	-1.1 (-12.8%)	-1.1 (-32.4%)
deepseek3-671b	7168	32	8	4	7.415B	dense_matrix_dropless	9.4	4.2	-0.8 (-9.3%)	-0.8 (-23.5%)
llama4-17b-16e	5120	16	1	48	107.770B	default	170.5	95.2	0.0 (0.0%)	0.0 (0.0%)
llama4-17b-16e	5120	16	1	48	107.770B	triton	170.0	94.7	0.5 (0.3%)	0.5 (0.5%)
llama4-17b-16e	5120	16	1	48	107.770B	dense_matrix (capacity 1.25)	171.6	96.3	-1.1 (-0.6%)	-1.1 (-1.2%)
llama4-17b-16e	5120	16	1	48	107.770B	dense_matrix_dropless	171.6	96.3	-1.1 (-0.6%)	-1.1 (-1.2%)
qwen3-235b-a22b	4096	128	8	4	11.196B	default	74.7	66.9	0.0 (0.0%)	0.0 (0.0%)
qwen3-235b-a22b	4096	128	8	4	11.196B	triton	24.4	16.5	50.3 (67.3%)	50.4 (75.3%)
qwen3-235b-a22b	4096	128	8	4	11.196B	dense_matrix (capacity 1.25)	23.2	15.4	51.5 (68.9%)	51.5 (77.0%)
qwen3-235b-a22b	4096	128	8	4	11.196B	dense_matrix_dropless	28.8	21.0	45.9 (61.4%)	45.9 (68.6%)
qwen3-30b-a3b	2048	128	8	48	30.532B	default	57.7	36.4	0.0 (0.0%)	0.0 (0.0%)
qwen3-30b-a3b	2048	128	8	48	30.532B	triton	45.1	23.7	12.6 (21.8%)	12.7 (34.9%)
qwen3-30b-a3b	2048	128	8	48	30.532B	dense_matrix (capacity 1.25)	44.8	23.5	12.9 (22.4%)	12.9 (35.4%)
qwen3-30b-a3b	2048	128	8	48	30.532B	dense_matrix_dropless	46.2	24.9	11.5 (19.9%)	11.5 (31.6%)
mixtral-8x7b	4096	8	2	32	46.703B	default	120.2	54.9	0.0 (0.0%)	0.0 (0.0%)
mixtral-8x7b	4096	8	2	32	46.703B	triton	115.2	50.0	5.0 (4.2%)	4.9 (8.9%)
mixtral-8x7b	4096	8	2	32	46.703B	dense_matrix (capacity 1.25)	115.2	49.9	5.0 (4.2%)	5.0 (9.1%)
mixtral-8x7b	4096	8	2	32	46.703B	dense_matrix_dropless	117.9	52.7	2.3 (1.9%)	2.2 (4.0%)
mixtral-8x7b (large)	4096	8	2	32	46.703B	default	79.9	47.2	0.0 (0.0%)	0.0 (0.0%)
mixtral-8x7b (large)	4096	8	2	32	46.703B	triton	73.7	41.1	6.2 (7.8%)	6.1 (12.9%)
mixtral-8x7b (large)	4096	8	2	32	46.703B	dense_matrix (capacity 1.25)	73.6	41.0	6.3 (7.9%)	6.2 (13.1%)
mixtral-8x7b (large)	4096	8	2	32	46.703B	dense_matrix_dropless	77.3	44.7	2.6 (3.3%)	2.5 (5.3%)

Regarding memory usage, the measured memory footprints confirm that the Group-GEMM backends make better use of memory for ragged-dot operations than the default XLA backend by avoiding the storage of unnecessary intermediate data. Indeed, the default backend rewrites the single ragged-dot(lhs[M,K], rhs[E,K,N]) → out[M,N] into E independent dot products, each over the full M rows — i.e. it computes an E × [M, N] stack of results (and the matching E × [M, ·] activations) and then masks each expert’s output down to the rows that actually belong to it. So every expert redundantly processes all M tokens, and the intermediate/output tensors blow up by a factor of E. Thus, the baseline’s wasted memory scales roughly as E × M × N, whereas Group-GEMM keeps a single compact [M, N] output. The savings are therefore largest when the product E × M × N is large — many experts, a large routed-token dimension M, and/or a wide output N — and small when any of those is small.

The measured numbers line up with this:

• qwen3-235b-a22b (MI350) —128 experts and a large routed-token workload (94 layers, seq 2048, top-8). Its baseline temp memory is66.9 GB , of which Group-GEMM removes50.4 GB (75.3%) — by far the biggest saving in the tables. With 128 experts each redundantly processing allM tokens, theE × [M, N] stack is enormous, and Group-GEMM never builds it.
• gemma4-26b (MI300) —128 experts and many routed tokens (top-8), even though the expert width is small (N = 704 ):17.3 GB (40.0%) of temp memory saved. The largeE (×M ) dominates the blow-up.
• qwen3-30b-a3b (MI300 & MI350) —128 experts ,N = 768 , top-8:≈13 GB (~35%) temp saved on both targets — the same many-experts effect.
• mixtral-8x7b (only 8 experts) — despite largeM /N , only**~5 GB (~10%)** temp saved: with just 8 experts theE × factor is small, so the redundant stack is comparatively cheap and there is little to reclaim.
• deepseek3-671b-reduced —0 GB (0%) : expert-parallel with only a few experts per GPU and very few tokens per step, soE × M is tiny and there is essentially nothing to remove.
• llama4-17b-16e (MI350) —0.5 GB (0.5%) : only 16 experts andtop-1 routing (small routed-token count), combined with wide dense GEMMs — a smallE × M , so the baseline’s redundant stack is modest.

Now, if we compare the memory usage of ragged-dot Group-GEMM against dense-matrix approaches, we notice that in most cases the memory usage is quite similar. This can be explained by:

• the fact that MaxText does not allocate extra matrices to process the data. It only uses the activation matrix as it is, using masking and data movements to compute the experts’ FFNs.
• in our experiment, the drop capacity is quite low (1.25), which does not incur significant data padding.

Part 5 — Conclusion and Next Steps# #

Using Group-GEMM as the backend for XLA ragged-dot brings two clear advantages: it is faster (no padding FLOPs) and it uses less memory (no expansion/padding). And XLA now offers two ways to get there:

• hipBLASLt — a vendor-library backend on AMD ROCm, extending XLA’s existing hipBLASLt matmul path
• Triton — a portable, autotunable, code-generated backend that runs on both CUDA and ROCm, currently experimental and off by default.

Next steps:

• Autotuner-driven backend selection. As mentioned earlier, the current selection ofragged-dot backends is based on static rules. Given that performance on different targets and the scope for fusion and optimization can vary from one operation to another, a next step forragged-dot backends would be to delegate the selection of the backend to the XLA autotuner.
• Faster data pre-/post-processing around ragged-dot. As highlighted inThe Three MoE Compute Paths in MaxText , the sparse (ragged-dot) path pays for apermute (sort tokens by expert + buildgroup_sizes ) before the Group-GEMM and anun-permute (scatter back + weighted combine) after it. This pre-processing can dominate the layer, capping the end-to-end speedup even when the Group-GEMM kernel itself is fast. Improving this pre-/post-processing is therefore a key next step to reduce the routing overhead and fully unlock the performance of the XLA Group-GEMM backend.

Summary# #

In this blog post, we showed how XLA turns the jax.lax.ragged_dot operation into real Group-GEMM on GPUs, avoiding the wasted compute and memory of the padded-dot baseline.

We built that argument in five parts, each with a distinct role. Part 1 framed the problem, moving from the MoE layer a model author writes to the ragged matmul a compiler actually sees, and identified Group-GEMM as the primitive that removes the padded baseline’s two costs. Part 2 and Part 3 then gave two implementations of that idea — one driving a vendor library (hipBLASLt), the other generating code (Triton). Part 4 supplied the evidence, and is also where the honest limits surfaced: the kernels are dramatically faster in isolation, yet the end-to-end gain is capped by the permute/un-permute routing overhead that surrounds them. Part 5 concludes on the Group-GEMM support and proposes a roadmap for future improvements.

Along the way, the key takeaways were:

• Two GPU backends. We delivered (1) ahipBLASLt backend on AMD ROCm that extends XLA’s existing matmul path and bridges the compile-time/runtime gap by filling the Group-GEMM descriptors from the runtimegroup_sizes ; and (2) aportable Triton code-generation backend that runs on both CUDA and ROCm and emits a specialized kernel for each ragged-dot variant (non-contracting, contracting, and batch).
• Performance and memory results. On real MaxText MoE models, the Group-GEMM backends deliver significant end-to-end speedups (up to ~6.7× on MI300 and ~5.4× on MI350) over the padded-dot baseline, with hipBLASLt generally ahead of Triton. They also substantially reduce activation memory — the savings scale withE × M × N , reaching ~75% temp-memory savings for many-expert models such asqwen3-235b-a22b . We also saw that, for the relatively small models evaluated, the permute/un-permute pre-processing overhead can offset the raw matmul efficiency, which is why improving that routing overhead is a key next step.

By reading this post you learned what MoE looks like to a compiler, why ragged-dot/Group-GEMM is the right abstraction, how each backend is implemented inside XLA, and how to enable and evaluate them on AMD GPUs.

Appendix: Micro-Benchmark Full Results# #

Table 12 below reports the full per-class TFLOP/s results for every measured shape in the micro-benchmark of Micro-Benchmark, across the three backends (default padded-dot baseline, triton, and hipblas).

Table 12: Full per-class micro-benchmark results (TFLOP/s) on MI300.

class	M	K	N	E	backend	tflops	status
fwd_wi	3840	2048	1408	64	default	6.85	ok
fwd_wi	3840	2048	1408	64	triton	86.44	ok
fwd_wi	3840	2048	1408	64	hipblas	135.21	ok
fwd_wo	3840	2048	1408	64	default	9.04	ok
fwd_wo	3840	2048	1408	64	triton	94.14	ok
fwd_wo	3840	2048	1408	64	hipblas	120.85	ok
dgrad_wi	3840	2048	1408	64	default	8.50	ok
dgrad_wi	3840	2048	1408	64	triton	87.50	ok
dgrad_wi	3840	2048	1408	64	hipblas	159.97	ok
wgrad_wi	3840	2048	1408	64	default	8.79	ok
wgrad_wi	3840	2048	1408	64	triton	94.40	ok
wgrad_wi	3840	2048	1408	64	hipblas	102.22	ok
dgrad_wo	3840	2048	1408	64	default	6.49	ok
dgrad_wo	3840	2048	1408	64	triton	82.86	ok
dgrad_wo	3840	2048	1408	64	hipblas	119.83	ok
wgrad_wo	3840	2048	1408	64	default	8.80	ok
wgrad_wo	3840	2048	1408	64	triton	81.52	ok
wgrad_wo	3840	2048	1408	64	hipblas	104.17	ok
fwd_wi	1920	5120	1536	160	default	3.43	ok
fwd_wi	1920	5120	1536	160	triton	31.05	ok
fwd_wi	1920	5120	1536	160	hipblas	44.31	ok
fwd_wo	1920	5120	1536	160	default	4.13	ok
fwd_wo	1920	5120	1536	160	triton	36.06	ok
fwd_wo	1920	5120	1536	160	hipblas	33.43	ok
dgrad_wi	1920	5120	1536	160	default	3.28	ok
dgrad_wi	1920	5120	1536	160	triton	34.16	ok
dgrad_wi	1920	5120	1536	160	hipblas	38.35	ok
wgrad_wi	1920	5120	1536	160	default	3.72	ok
wgrad_wi	1920	5120	1536	160	triton	4.50	ok
wgrad_wi	1920	5120	1536	160	hipblas	26.74	ok
dgrad_wo	1920	5120	1536	160	default	2.95	ok
dgrad_wo	1920	5120	1536	160	triton	30.68	ok
dgrad_wo	1920	5120	1536	160	hipblas	45.01	ok
wgrad_wo	1920	5120	1536	160	default	3.68	ok
wgrad_wo	1920	5120	1536	160	triton	4.50	ok
wgrad_wo	1920	5120	1536	160	hipblas	26.80	ok
fwd_wi	5120	512	512	256	default	2.02	ok
fwd_wi	5120	512	512	256	triton	32.98	ok
fwd_wi	5120	512	512	256	hipblas	24.19	ok
fwd_wo	5120	512	512	256	default	2.02	ok
fwd_wo	5120	512	512	256	triton	33.16	ok
fwd_wo	5120	512	512	256	hipblas	26.19	ok
dgrad_wi	5120	512	512	256	default	1.92	ok
dgrad_wi	5120	512	512	256	triton	34.07	ok
dgrad_wi	5120	512	512	256	hipblas	27.99	ok
wgrad_wi	5120	512	512	256	default	1.52	ok
wgrad_wi	5120	512	512	256	triton	26.85	ok
wgrad_wi	5120	512	512	256	hipblas	24.98	ok
dgrad_wo	5120	512	512	256	default	1.92	ok
dgrad_wo	5120	512	512	256	triton	33.37	ok
dgrad_wo	5120	512	512	256	hipblas	26.36	ok
wgrad_wo	5120	512	512	256	default	1.53	ok
wgrad_wo	5120	512	512	256	triton	26.85	ok
wgrad_wo	5120	512	512	256	hipblas	24.53	ok
fwd_wi	10240	2816	704	128	default	2.14	ok
fwd_wi	10240	2816	704	128	triton	110.97	ok
fwd_wi	10240	2816	704	128	hipblas	172.24	ok
fwd_wo	10240	2816	704	128	default	5.66	ok
fwd_wo	10240	2816	704	128	triton	128.01	ok
fwd_wo	10240	2816	704	128	hipblas	137.69	ok
dgrad_wi	10240	2816	704	128	default	5.47	ok
dgrad_wi	10240	2816	704	128	triton	128.28	ok
dgrad_wi	10240	2816	704	128	hipblas	175.65	ok
wgrad_wi	10240	2816	704	128	default	3.62	ok
wgrad_wi	10240	2816	704	128	triton	116.71	ok
wgrad_wi	10240	2816	704	128	hipblas	104.51	ok
dgrad_wo	10240	2816	704	128	default	2.19	ok
dgrad_wo	10240	2816	704	128	triton	105.61	ok
dgrad_wo	10240	2816	704	128	hipblas	176.18	ok
wgrad_wo	10240	2816	704	128	default	3.67	ok
wgrad_wo	10240	2816	704	128	triton	96.62	ok
wgrad_wo	10240	2816	704	128	hipblas	113.53	ok
fwd_wi	10240	2880	2880	128	default	4.46	ok
fwd_wi	10240	2880	2880	128	triton	128.32	ok
fwd_wi	10240	2880	2880	128	hipblas	200.81	ok
fwd_wo	10240	2880	2880	128	default	4.46	ok
fwd_wo	10240	2880	2880	128	triton	127.71	ok
fwd_wo	10240	2880	2880	128	hipblas	199.25	ok
dgrad_wi	10240	2880	2880	128	default	4.33	ok
dgrad_wi	10240	2880	2880	128	triton	126.28	ok
dgrad_wi	10240	2880	2880	128	hipblas	242.96	ok
wgrad_wi	10240	2880	2880	128	default	4.90	ok
wgrad_wi	10240	2880	2880	128	triton	130.05	ok
wgrad_wi	10240	2880	2880	128	hipblas	127.73	ok
dgrad_wo	10240	2880	2880	128	default	4.32	ok
dgrad_wo	10240	2880	2880	128	triton	125.88	ok
dgrad_wo	10240	2880	2880	128	hipblas	242.90	ok
wgrad_wo	10240	2880	2880	128	default	4.91	ok
wgrad_wo	10240	2880	2880	128	triton	129.74	ok
wgrad_wo	10240	2880	2880	128	hipblas	128.08	ok
fwd_wi	1280	5120	8192	16	default	44.77	ok
fwd_wi	1280	5120	8192	16	triton	133.88	ok
fwd_wi	1280	5120	8192	16	hipblas	220.41	ok
fwd_wo	1280	5120	8192	16	default	35.27	ok
fwd_wo	1280	5120	8192	16	triton	129.44	ok
fwd_wo	1280	5120	8192	16	hipblas	224.86	ok
dgrad_wi	1280	5120	8192	16	default	27.50	ok
dgrad_wi	1280	5120	8192	16	triton	96.85	ok
dgrad_wi	1280	5120	8192	16	hipblas	246.03	ok
wgrad_wi	1280	5120	8192	16	default	40.48	ok
wgrad_wi	1280	5120	8192	16	triton	113.19	ok
wgrad_wi	1280	5120	8192	16	hipblas	154.65	ok
dgrad_wo	1280	5120	8192	16	default	32.66	ok
dgrad_wo	1280	5120	8192	16	triton	130.98	ok
dgrad_wo	1280	5120	8192	16	hipblas	232.46	ok
wgrad_wo	1280	5120	8192	16	default	41.02	ok
wgrad_wo	1280	5120	8192	16	triton	117.14	ok
wgrad_wo	1280	5120	8192	16	hipblas	154.67	ok
fwd_wi	15360	6144	20480	32	default	24.73	ok
fwd_wi	15360	6144	20480	32	triton	261.23	ok
fwd_wi	15360	6144	20480	32	hipblas	527.94	ok
fwd_wo	15360	6144	20480	32	default	17.97	ok
fwd_wo	15360	6144	20480	32	triton	233.12	ok
fwd_wo	15360	6144	20480	32	hipblas	471.04	ok
dgrad_wi	15360	6144	20480	32	default	17.71	ok
dgrad_wi	15360	6144	20480	32	triton	244.21	ok
dgrad_wi	15360	6144	20480	32	hipblas	485.43	ok
wgrad_wi	15360	6144	20480	32	default	24.57	ok
wgrad_wi	15360	6144	20480	32	triton	284.41	ok
wgrad_wi	15360	6144	20480	32	hipblas	428.84	ok
dgrad_wo	15360	6144	20480	32	default	24.01	ok
dgrad_wo	15360	6144	20480	32	triton	266.45	ok
dgrad_wo	15360	6144	20480	32	hipblas	470.12	ok
wgrad_wo	15360	6144	20480	32	default	24.62	ok
wgrad_wo	15360	6144	20480	32	triton	283.80	ok
wgrad_wo	15360	6144	20480	32	hipblas	431.66	ok
fwd_wi	40960	8192	28672	64	default	8.80	ok
fwd_wi	40960	8192	28672	64	triton	294.11	ok
fwd_wi	40960	8192	28672	64	hipblas	510.97	ok
fwd_wo	40960	8192	28672	64	default		OOM
fwd_wo	40960	8192	28672	64	triton	298.32	ok
fwd_wo	40960	8192	28672	64	hipblas	507.20	ok
dgrad_wi	40960	8192	28672	64	default		OOM
dgrad_wi	40960	8192	28672	64	triton	299.03	ok
dgrad_wi	40960	8192	28672	64	hipblas	464.65	ok
wgrad_wi	40960	8192	28672	64	default		OOM
wgrad_wi	40960	8192	28672	64	triton	78.34	ok
wgrad_wi	40960	8192	28672	64	hipblas	318.52	ok
dgrad_wo	40960	8192	28672	64	default	8.74	ok
dgrad_wo	40960	8192	28672	64	triton	308.75	ok
dgrad_wo	40960	8192	28672	64	hipblas	497.37	ok
wgrad_wo	40960	8192	28672	64	default		OOM
wgrad_wo	40960	8192	28672	64	triton	51.84	ok
wgrad_wo	40960	8192	28672	64	hipblas	336.43	ok
fwd_wi	20480	4096	1536	128	default	3.82	ok
fwd_wi	20480	4096	1536	128	triton	168.07	ok
fwd_wi	20480	4096	1536	128	hipblas	332.96	ok
fwd_wo	20480	4096	1536	128	default	5.71	ok
fwd_wo	20480	4096	1536	128	triton	176.82	ok
fwd_wo	20480	4096	1536	128	hipblas	323.89	ok
dgrad_wi	20480	4096	1536	128	default	5.61	ok
dgrad_wi	20480	4096	1536	128	triton	190.20	ok
dgrad_wi	20480	4096	1536	128	hipblas	291.06	ok
wgrad_wi	20480	4096	1536	128	default	4.82	ok
wgrad_wi	20480	4096	1536	128	triton	175.78	ok
wgrad_wi	20480	4096	1536	128	hipblas	236.19	ok
dgrad_wo	20480	4096	1536	128	default	4.43	ok
dgrad_wo	20480	4096	1536	128	triton	172.91	ok
dgrad_wo	20480	4096	1536	128	hipblas	324.73	ok
wgrad_wo	20480	4096	1536	128	default	4.85	ok
wgrad_wo	20480	4096	1536	128	triton	176.91	ok
wgrad_wo	20480	4096	1536	128	hipblas	232.07	ok
fwd_wi	10240	2048	768	128	default	3.33	ok
fwd_wi	10240	2048	768	128	triton	111.85	ok
fwd_wi	10240	2048	768	128	hipblas	171.38	ok
fwd_wo	10240	2048	768	128	default	5.59	ok
fwd_wo	10240	2048	768	128	triton	116.12	ok
fwd_wo	10240	2048	768	128	hipblas	135.95	ok
dgrad_wi	10240	2048	768	128	default	5.39	ok
dgrad_wi	10240	2048	768	128	triton	115.59	ok
dgrad_wi	10240	2048	768	128	hipblas	144.88	ok
wgrad_wi	10240	2048	768	128	default	3.87	ok
wgrad_wi	10240	2048	768	128	triton	99.24	ok
wgrad_wi	10240	2048	768	128	hipblas	121.36	ok
dgrad_wo	10240	2048	768	128	default	3.25	ok
dgrad_wo	10240	2048	768	128	triton	106.70	ok
dgrad_wo	10240	2048	768	128	hipblas	171.31	ok
wgrad_wo	10240	2048	768	128	default	3.87	ok
wgrad_wo	10240	2048	768	128	triton	97.99	ok
wgrad_wo	10240	2048	768	128	hipblas	122.84	ok
fwd_wi	6400	2048	512	512	default	1.11	ok
fwd_wi	6400	2048	512	512	triton	29.18	ok
fwd_wi	6400	2048	512	512	hipblas	25.16	ok
fwd_wo	6400	2048	512	512	default	1.34	ok
fwd_wo	6400	2048	512	512	triton	30.86	ok
fwd_wo	6400	2048	512	512	hipblas	16.43	ok
dgrad_wi	6400	2048	512	512	default	1.27	ok
dgrad_wi	6400	2048	512	512	triton	27.83	ok
dgrad_wi	6400	2048	512	512	hipblas	17.26	ok
wgrad_wi	6400	2048	512	512	default	0.88	ok
wgrad_wi	6400	2048	512	512	triton	1.82	ok
wgrad_wi	6400	2048	512	512	hipblas	13.86	ok
dgrad_wo	6400	2048	512	512	default	1.06	ok
dgrad_wo	6400	2048	512	512	triton	27.49	ok
dgrad_wo	6400	2048	512	512	hipblas	30.17	ok
wgrad_wo	6400	2048	512	512	default	0.87	ok
wgrad_wo	6400	2048	512	512	triton	1.82	ok
wgrad_wo	6400	2048	512	512	hipblas	13.80	ok

Disclaimers# #

The information presented in this document is for informational purposes only and may contain technical inaccuracies, omissions, and typographical errors. The information contained herein is subject to change and may be rendered inaccurate for many reasons, including but not limited to product and roadmap changes, component and motherboard version changes, new model and/or product releases, product differences between differing manufacturers, software changes, BIOS flashes, firmware upgrades, or the like. Any computer system has risks of security vulnerabilities that cannot be completely prevented or mitigated. AMD assumes no obligation to update or otherwise correct or revise this information. However, AMD reserves the right to revise this information and to make changes from time to time to the content hereof without obligation of AMD to notify any person of such revisions or changes. THIS INFORMATION IS PROVIDED ‘AS IS.” AMD MAKES NO REPRESENTATIONS OR WARRANTIES WITH RESPECT TO THE CONTENTS HEREOF AND ASSUMES NO RESPONSIBILITY FOR ANY INACCURACIES, ERRORS, OR OMISSIONS THAT MAY APPEAR IN THIS INFORMATION. AMD SPECIFICALLY DISCLAIMS ANY IMPLIED WARRANTIES OF NON-INFRINGEMENT, MERCHANTABILITY, OR FITNESS FOR ANY PARTICULAR PURPOSE. IN NO EVENT WILL AMD BE LIABLE TO ANY PERSON FOR ANY RELIANCE, DIRECT, INDIRECT, SPECIAL, OR OTHER CONSEQUENTIAL DAMAGES ARISING FROM THE USE OF ANY INFORMATION CONTAINED HEREIN, EVEN IF AMD IS EXPRESSLY ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. AMD, the AMD Arrow logo, [insert all other AMD trademarks used in the material here per AMD Trademarks] and combinations thereof are trademarks of Advanced Micro Devices, Inc. Other product names used in this publication are for identification purposes only and may be trademarks of their respective companies. [Insert any third party trademark attribution here per AMD’s Third Party Trademark List.] © [Insert year written*] Advanced Micro Devices, Inc. All rights reserved

source & further reading

rocm.blogs.amd.com — original article Accelerating MONAI Digital-Pathology Pipelines on AMD Instinct™ GPUs with hipCIM Ultralytics YOLO on AMD GPUs: Train, Run, and Deploy with ROCm™ FP8 GEMM Optimization on AMD RDNA™ 4 Architecture
