TL;DR: We put NVIDIA's new Vera CPU through its paces using the full TPC-H workload on scale factor 1,000.
We love running benchmarks on all sorts of new hardware. This often includes somewhat exotic hardware – where we sometimes need to compile a new DuckDB binary. This time, in collaboration with the NVIDIA team, we got our hands on their new Vera chip, aimed at agentic workloads.
NVIDIA Vera comes with 88 “Olympus” cores, Spatial Multithreading and up to 1.2 terabytes per second (TB/s) of memory bandwidth. What's more, Vera runs arm64 binaries – so it runs DuckDB's regular build without any modifications.
To see how this new hardware performs, we ran the full TPC-H benchmark (not just the read queries!) on scale factor 1,000. Our setup included two server platforms: an x86 baseline (Intel Xeon 6) and NVIDIA Vera.
#
Environment
System Setup
Both machines ran Ubuntu 26.04.
Their hardware included 768 GB of memory and a single NVMe SSD with 3+ TB of storage, formatted as ext4.
At the time of writing, DuckDB v2.0 was not released yet, so we used a preview build, 1.6.0.dev379.
To run the experiments, we used the duckdb-tpch benchmark harness.
To re-create our benchmark environment, see our script below.
Click here to reveal the setup script. #
sudo apt install git g++ cmake python3-pip
git clone https://github.com/duckdb/duckdb-tpch
cd duckdb-tpch
git reset --hard cf096cea8a0a054cefe0e695c842ca5bca6ec04d
python3 -m venv venv
source venv/bin/activate
python3 -m pip install -r requirements.txt
python3 -m pip install duckdb==1.6.0.dev379
cd tpch_tools_3.0.1/dbgen/
make
cd ../..
export SF=1000
./generate.sh
Tip To generate the large-scale TPC-H dataset efficiently,
the repository uses the wonderful tpchgen-cli tool,
a parallel Rust rewrite of the TPC-H data generator.
It also uses the old generator to produce update and query streams.
This workload is relatively large-scale (SF1,000) and highly concurrent during the throughput run. To get the best performance out of DuckDB, we set the following flags:
SET block_allocator_memory = '500G';
SET allocator_background_threads = true;
x86 Baseline: Intel Xeon 6
The x86 baseline setup used an Intel Xeon 6 CPU. The CPU had 96 cores with hyper-threading, yielding 192 threads. However, we found that DuckDB performs best when using 96 threads, so we configured it accordingly:
SET threads = 96;
NVIDIA Vera
The second machine had the NVIDIA Vera CPU, which packs 88 cores with Spatial Multithreading.
We conducted the benchmark on a dual-socket system but restricted DuckDB to a single socket using the numactl command:
numactl --cpunodebind=0 --membind=0 python3 benchmark.py
We also pinned the number of threads:
SET threads = 88;
#
Benchmark Runs and Results
We performed an initial warmup run and discarded its result. Then, we conducted three complete runs in sequence and took the median value of the QphH@Size composite scores:
| x86 QphH@Size | Vera QphH@Size | |
|---|---|---|
| Run 1 | 2,120,588.82 | 3,073,292.99 |
| Run 2 | 2,022,795.01 | 3,131,306.27 |
| Run 3 | 2,109,782.19 | 3,052,102.87 |
| Median score | 2,109,782.19 | 3,073,292.99 |
The results show that the Vera platform has a 46% performance advantage on TPC-H SF1,000 over the x86 baseline (Intel Xeon 6). In fact, if we were to audit these results through the official TPC-H channels, both would stand a chance to be in the top 3 among the TPC-H Top Performance Results on SF1,000.
We attribute the performance advantage of Vera to three key factors. First, the high memory bandwidth enables fast scans. Second, combined with low memory latency, it keeps the cores continuously occupied during processing. Finally, the Olympus cores' large caches allow efficient access to the hash tables built during aggregations and joins.
We are looking forward to continuing this benchmark by using DuckDB v2.0.0's stable build, running on the full dual-socket setup and incorporating different benchmarks.
