The Model Context Protocol (MCP) has become a standard way for AI agents to discover the tools an application, database, or service offers. Claude Code, Codex, Cursor, Antigravity, et al. can connect to an MCP server, ask it what tools are available, and call these tools instead of figuring out what they can or can't do on the fly or piecing together API calls. Setting up an MCP server for a database usually means running a separate process that holds a database credential and turns tool calls into queries. Then you have another process to deploy, another place a credential lives, and a set of guardrails that sit outside the database.
The vsql-mcp extension from VillageSQL takes a different approach. It puts the MCP server inside the database. Install it, set a handful of global variables, and your MySQL server itself serves MCP over Streamable HTTP from a background worker in the database server process. There's no sidecar to run, and the rules about what an agent can see and do are server state: you set them with SET GLOBAL, read them with SHOW VARIABLES, and watch them work with SHOW STATUS.
VillageSQL is the innovation platform for MySQL that adds an extension framework (similar to PostgreSQL's extension framework) to enable permissionless innovation. Instead of waiting for a feature to be implemented in a few years in a future version of MySQL, new functionality can be dynamically added to a version of MySQL you run today.
The extension comes packaged with a set of six tools. list_schemas, list_tables, and describe_table browse what you expose. query runs one read-only SELECT, and explain returns its plan. write is the sixth, and it stays off until you turn it on; until then an agent cannot see that it exists. Two MCP resources come with the tools: a schema overview and a table's CREATE TABLE. Guidance on adding your own tools is at the bottom of this post.
The rest of this post walks through using the extension end to end.
If you would rather stop reading here and have your AI agent demonstrate this for you, open this dropdown and copy the prompt into your preferred AI coding tool. #
Set up a working demo of the vsql-mcp extension for VillageSQL, which serves
the Model Context Protocol from inside the database server. Work only against
a local throwaway server, and if the only VillageSQL or MySQL server you find
looks like something I depend on, stop and ask me before touching it.
Do all of this yourself, and show me the real output of each step:
1. Find a VillageSQL server, or install one. The install script needs a
codebase and a method:
`curl -fsSL https://install.villagesql.com | VSQL_CODEBASE=mysql-8.4 INSTALL_METHOD=prebuilt bash`.
Start it with `--vsql_allow_preview_extensions=ON`; on a server already
running, `SET PERSIST vsql_allow_preview_extensions=ON` takes effect at
once. Confirm with `SELECT VERSION()` before continuing.
2. Build the extension. It is not bundled with the server yet. Install the
tooling with `cargo install cargo-vsql`, clone
https://github.com/villagesql/vsql-mcp, run `cargo vsql package` in it,
and copy `dist/vsql_mcp.veb` into the directory
`SHOW VARIABLES LIKE 'veb_dir'` names. You need a Rust toolchain, 1.87 or
newer. The SDK comes from crates.io.
3. Create a small demo schema with two related tables and a few dozen rows,
then run `INSTALL EXTENSION vsql_mcp;` and show me the settings that
appeared under `SHOW GLOBAL VARIABLES LIKE 'vsql_mcp%'`.
4. Configure it the least-privilege way: a dedicated database account with
SELECT on the demo schema only, `vsql_mcp.db_url` pointing at that
account, `vsql_mcp.schema` set to the demo schema, `require_auth` ON with
a random bearer token, and a free port. Turn `vsql_mcp.vsql_mcp_enabled`
ON and prove it is listening with `SELECT vsql_mcp.info();`.
5. Register the endpoint with yourself (for Claude Code:
`claude mcp add --transport http vsql http://127.0.0.1:PORT/mcp --header
"Authorization: Bearer TOKEN"`), then answer a question about the demo
data using only the MCP tools, and show me which tools you called.
6. Try to break it. Send a request with no bearer token and show the 401.
Ask the query tool to run an UPDATE. Query a table in another schema.
Set `vsql_mcp.allowed_tables` to one table and show that the others
disappear from list_tables and refuse describe_table. Show me each
refusal message.
Then give me a table of what you ran and what came back, tell me anything
that did not behave the way this asked, and drop every user, schema, and
setting you created, remove the MCP registration, and leave my machine the
way you found it.
Build it #
vsql-mcp is written in Rust and uses "preview capabilities" of the VillageSQL Extension Framework (VEF). It isn't bundled with the server as of this writing, so you must build it yourself. You need a Rust toolchain (1.87 or newer) and the cargo-vsql tool. The VillageSQL Rust SDK comes from crates.io, so there is nothing else to clone:
cargo install cargo-vsql
git clone https://github.com/villagesql/vsql-mcp
cd vsql-mcp
cargo vsql package
That produces dist/vsql_mcp.veb. Copy it into your server's extension directory, which the server can help you identify:
SHOW VARIABLES LIKE 'veb_dir';
Connect an agent #
The examples below use a toy shop schema. Create it to follow along:
CREATE DATABASE shop;
USE shop;
CREATE TABLE customers (
id INT PRIMARY KEY AUTO_INCREMENT,
name VARCHAR(80) NOT NULL,
country CHAR(2) NOT NULL,
joined DATE NOT NULL
);
CREATE TABLE orders (
id INT PRIMARY KEY AUTO_INCREMENT,
customer_id INT NOT NULL,
placed_on DATE NOT NULL,
status ENUM('pending','shipped','delivered','cancelled') NOT NULL,
total DECIMAL(10,2) NOT NULL,
FOREIGN KEY (customer_id) REFERENCES customers(id)
);
INSERT INTO customers (name, country, joined) VALUES
('Carla Reyes', 'MX', '2024-02-11'),
('Ben Osei', 'GH', '2024-03-02'),
('Grace Liu', 'SG', '2024-03-19'),
('Tomas Vrba', 'CZ', '2024-05-07'),
('Priya Nair', 'IN', '2024-06-23'),
('Mei Tanaka', 'JP', '2024-08-14');
INSERT INTO orders (customer_id, placed_on, status, total) VALUES
(1, '2024-04-03', 'delivered', 150.00),
(1, '2024-07-21', 'delivered', 270.00),
(1, '2024-09-02', 'cancelled', 80.00),
(2, '2024-04-18', 'delivered', 99.95),
(2, '2024-08-30', 'delivered', 210.50),
(3, '2024-05-26', 'delivered', 76.25),
(3, '2024-09-11', 'delivered', 200.00),
(4, '2024-06-14', 'delivered', 180.00),
(4, '2024-10-05', 'shipped', 60.00),
(5, '2024-07-08', 'delivered', 120.00),
(5, '2024-10-19', 'pending', 900.00),
(6, '2024-09-27', 'delivered', 95.50),
(6, '2024-10-23', 'cancelled', 40.00);
Exposing it to agents is one server setting, one INSTALL EXTENSION, one least-privilege account, and six extension settings, all run as an administrator:
-- vsql-mcp declares VEF preview capabilities. SET PERSIST takes effect at
-- once; a server you start yourself can take --vsql_allow_preview_extensions=ON.
SET PERSIST vsql_allow_preview_extensions = ON;
INSTALL EXTENSION vsql_mcp;
-- A dedicated least-privilege account the server runs tool queries as.
CREATE USER 'mcp'@'127.0.0.1' IDENTIFIED BY 'change-me';
GRANT SELECT ON shop.* TO 'mcp'@'127.0.0.1';
SET GLOBAL vsql_mcp.db_url = 'mysql://mcp:change-me@127.0.0.1:3399';
SET GLOBAL vsql_mcp.schema = 'shop';
SET GLOBAL vsql_mcp.require_auth = ON;
SET GLOBAL vsql_mcp.bearer_token = 'a-long-random-token';
SET GLOBAL vsql_mcp.port = 3400;
SET GLOBAL vsql_mcp.vsql_mcp_enabled = ON;
The db_url line is the important one. Queries, EXPLAINs, writes, and a table's CREATE TABLE all reach the database over a loopback connection as that account. Schema and table browsing runs inside the server instead, so it does not need db_url. That account's GRANT s are the real access boundary; the read-only and allowlist checks on top are defense in depth. Here the account can read the shop schema and nothing else.
The port defaults to 3100; these examples use 3400 because something else already had 3100. The server is now listening:
SELECT vsql_mcp.info();
{"enabled":true,"http_port":3400,"https_port":0,"port":3400,
"protocol_version":"2025-06-18","schema":"shop","sessions_active":0,"ssl_port":3143}
http_port and https_port are what's actually listening. ssl_port is only the configured default (3143), and https_port stays 0 because HTTPS starts only when vsql_mcp.ssl_cert and vsql_mcp.ssl_key are set.
Registering it with Claude Code is one command, and any client that speaks MCP over Streamable HTTP connects the same way, with a URL and a bearer header. There's no stdio transport, since there's no child process to spawn, so a stdio-only client needs a bridge in front (the README covers that, plus the equivalent setup for Codex and Antigravity):
claude mcp add --transport http vsql http://127.0.0.1:3400/mcp \
--header "Authorization: Bearer a-long-random-token"
That's the whole integration. Ask a question:
claude -p "Which customer has the highest total value of delivered orders? \
Use the vsql MCP tools." --allowedTools mcp__vsql
**Carla Reyes** has the highest total value of delivered orders: **$420.00**.
I joined `shop.customers` to `shop.orders`, kept only the rows with
`status = 'delivered'`, and summed `total` for each customer. The top results are:
| Customer | Delivered total |
|---|---|
| Carla Reyes | $420.00 |
| Ben Osei | $310.45 |
| Grace Liu | $276.25 |
A trace of the run shows the agent calling list_schemas, list_tables, and describe_table on both tables before writing the join and running it through the query tool. The database credential never left the server; the client got a URL and a bearer token, and nobody pasted a schema into a prompt. The query tool hands back JSON an agent can reason over. Here's the same question asked through it directly:
SELECT c.name, c.country, SUM(o.total) AS delivered_total
FROM shop.customers c
JOIN shop.orders o ON o.customer_id = c.id
WHERE o.status = 'delivered'
GROUP BY c.id, c.name, c.country
ORDER BY delivered_total DESC
LIMIT 3;
{
"columns": ["name", "country", "delivered_total"],
"row_count": 3,
"rows": [
{"name": "Carla Reyes", "country": "MX", "delivered_total": "420.00"},
{"name": "Ben Osei", "country": "GH", "delivered_total": "310.45"},
{"name": "Grace Liu", "country": "SG", "delivered_total": "276.25"}
],
"truncated": false
}
Push on the guardrails #
Sooner or later an agent asks for something you didn't intend to allow. vsql-mcp answers with a refusal that names the rule it hit, so an agent can read the message and adjust course instead of retrying blind.
The query tool accepts a single read-only statement. Asked to run an UPDATE, it answers:
only a single read-only statement is allowed by the query tool
Writes have their own tool, and it's off by default. Until you set vsql_mcp.allow_write = ON, the write tool is absent from tools/list entirely, so an agent never plans around a tool it cannot use. With this configuration, tools/list returns five tools.
With vsql_mcp.schema = 'shop', a query that reaches for another schema is refused:
schema 'mysql' is outside the exposed schema; only 'shop' is available,
and table names must be qualified with it
You can narrow it further. Setting vsql_mcp.allowed_tables = 'orders' confines the agent to named tables. The check runs on the statement's actual plan, so a join or subquery that touches an excluded table is caught too:
table 'customers' is not in vsql_mcp.allowed_tables
The one place the check doesn't reach is a stored function's body, which EXPLAIN doesn't descend into. The README covers it.
The allowlist also governs what an agent can learn, not only what it can read: describe_table refuses an excluded table, and list_tables omits it entirely.
Beyond those, max_rows caps every query result (and marks it truncated so the agent knows), query_timeout bounds each call, and requests without the bearer token get HTTP 401 before any of this runs. The transport also validates the Origin header, as the MCP spec requires; a request claiming to come from a non-local origin gets HTTP 403. The listener binds to 127.0.0.1 only, so exposing it beyond the machine is a decision you make deliberately, with a reverse proxy in front. The README lists the remaining boundaries plainly, and the boundary to design around is the grants. Guardrails narrow what an agent can do, and the db_url account's grants are what it can never exceed.
Watch the agent from SQL #
Because the MCP server is server state, you can monitor it the way you monitor everything else in MySQL. After the agent calls above:
SHOW STATUS LIKE 'vsql_mcp%';
+------------------------------+-------+
| Variable_name | Value |
+------------------------------+-------+
| vsql_mcp.http_port | 3400 |
| vsql_mcp.https_port | 0 |
| vsql_mcp.rows_returned_total | 11 |
| vsql_mcp.sessions_active | 5 |
| vsql_mcp.tool_calls_total | 15 |
| vsql_mcp.tool_errors_total | 6 |
+------------------------------+-------+
The refusals shown above are counted in tool_errors_total, along with any tool call that fails for ordinary reasons, like malformed SQL. If tool errors spike, something is off on the tool surface, whether that's an agent pushing at the rules or queries that simply fail, and you find out from the database rather than from a sidecar's log file.
Make it your own #
The six tools are a list in the extension's own source, and the extension is GPL-2.0 Rust you can fork and modify. src/tools.rs holds a JSON array that advertises each tool, and a match that routes a call to its handler — so adding one of your own is a few edits.
Say you want an agent to see a table's indexes before it writes a join. Advertise it in tool_definitions():
{
"name": "list_indexes",
"description": "Indexes on a table, one row per indexed column.",
"inputSchema": {
"type": "object",
"properties": {
"schema": { "type": "string" },
"table": { "type": "string" }
},
"required": ["table"]
}
},
Route it in call():
"list_indexes" => list_indexes(args, cfg, exec),
Then write the handler. It receives the call arguments, the live configuration, and the executor, and every seam the built-in tools use is available to it:
fn list_indexes(args: &Json, cfg: &RequestConfig, exec: &dyn QueryExecutor) -> Result<Json, String> {
let table = arg_str(args, "table")?;
let schema = effective_schema(args.get("schema").and_then(Json::as_str), cfg)?;
if !guardrails::table_allowed(table, &cfg.allowed_tables) {
return Err(format!("table '{table}' is not in vsql_mcp.allowed_tables"));
}
let rows = exec.read_params(
"SELECT INDEX_NAME, SEQ_IN_INDEX, COLUMN_NAME, NON_UNIQUE \
FROM information_schema.STATISTICS WHERE TABLE_SCHEMA = ? AND TABLE_NAME = ? \
ORDER BY INDEX_NAME, SEQ_IN_INDEX",
vec![MyValue::from(schema.clone()), MyValue::from(table.to_owned())],
&[
col("INDEX_NAME"),
numeric_col("SEQ_IN_INDEX"),
col("COLUMN_NAME"),
numeric_col("NON_UNIQUE"),
],
cfg.query_timeout,
)?;
let indexes: Vec<Json> = rows
.rows
.iter()
.map(|r| {
json!({
"name": field(r, "INDEX_NAME"),
"column": field(r, "COLUMN_NAME"),
"position": field(r, "SEQ_IN_INDEX"),
"unique": r.get("NON_UNIQUE").and_then(Json::as_i64) == Some(0)
})
})
.collect();
Ok(json!({ "schema": schema, "table": table, "indexes": indexes }))
}
Three of those lines are why you extend the extension instead of writing a sidecar. guardrails::table_allowed applies the operator's allowed_tables list, so the new tool honors a rule nobody had to teach it. effective_schema pins the call to the configured schema. And read_params runs a fixed-shape statement in-process through the sql_query capability, so a tool like this needs no db_url and opens no connection; arbitrary SQL goes through exec.read() over the loopback connection instead. The one import to add is numeric_col, alongside col at the top of the file.
Rebuild, then swap the package in while the extension is uninstalled:
cargo vsql package
UNINSTALL EXTENSION vsql_mcp;
Copy the new dist/vsql_mcp.veb into your veb_dir, replacing the old one, then:
INSTALL EXTENSION vsql_mcp;
The next tools/list includes list_indexes. Reinstalling returns every vsql_mcp.* setting to its default, including values you set with SET PERSIST, so re-apply the configuration afterward. Bump the version in manifest.json while you are in the tree, and run cargo vsql test: the mysql-test/ suite covers the protocol, the guardrails, and the refusals, so a change that breaks one of them fails before an agent finds it.
Try it out #
The vsql-mcp repository covers every setting, the client setup for Codex and Antigravity, and the current limitations. Point an agent at a schema you know well, watch what it asks for, and tell us where the guardrails helped or got in the way, on Discord or in a GitHub issue.
To get started with VillageSQL Server, go to villagesql.com.
